- 5 -

ENGLISH

GB

 GENERAL

Carefully read the following important information regarding

installation safety and maintenance. Keep this information

booklet accessible for further consultations. The appliance

has been designed for use in the ducting version (air exhaust

to the outside), filtering version (air circulation on the inside )

or with external motor.

 SAFETY PRECAUTION

1.

 Take care when the cooker hood is operating simultane-

ously with an open fireplace or burner that depend on the air

in the environment and are supplied by other than electrical

energy, as the cooker hood removes the air from the environ-

ment which a burner or fireplace need for combustion. The

negative pressure in the environment must not exceed 4Pa

(4x10-5 bar). Provide adequate ventilation in the environment

for a safe operation of the cooker hood. Follow the local laws

applicable for external air evacuation.

Before connecting the model to the electricity network:

- Control the data plate (positioned inside the appliance)

to ascertain that the voltage and power correspond to the

network and the socket is suitable. If in doubt ask a qualified

electrician.

- If the power supply cable is damaged, it must be replaced with

another cable or a special assembly, which may be obtained

direct from the manufacturer or from the Technical Assistance

Centre.

2. WARNING!

In certain circumstances electrical appliances may be a

danger hazard.

A) Do not check the status of the filters while the cooker

hood is operating.

B) Do not touch bulbs or adjacent areas, during or straight

after prolonged use of the lighting installation.

C) Flambè cooking is prohibited underneath the cooker

hood.

D) Avoid free flame, as it is damaging for the filters and a

fire hazard.

E) Constantly check food frying to avoid that the over-

heated oil may become a fire hazard.

F) Disconnect the electrical plug prior to any maintenance.

G) This appliance is not intended for use by young children

or infirm persons without supervision.

H) Young children should be supervised to ensure they do

not play with the appliance.

I)  There shall be adequate ventilation of the room when the

rangehood is used at the same time as appliances burning

gas or other fuels.

L) There is a risk of fire if cleaning is not carried out in ac-

cordance with the instructions.

This appliance conforms to the European Directive EC/2002/96,

Waste Electrical and Electronic Equipment (WEEE). By making

sure that this appliance is disposed of in a suitable manner, the

user is helping to prevent potential damage to the environ-

ment or to public health.

The symbol on the product or on the accompanying

paperwork indicates that the appliance should not be

treated as domestic waste, but should be delivered to a suit-

able electric and electronic appliance recycling collection

point. Follow local guidelines when disposing of waste. For

more information on the treatment, re-use and recycling of

this product, please contact your local authority, domestic

waste collection service or the shop where the appliance was

purchased.

 INSTALLATION INSTRUCTIONS

•  Assembly and electrical connections must be carried out

by specialised personnel.

•  Electric Connection:

The appliance has been manufactured as a class II, therefore

no earth cable is necessary.

The connection to the mains is carried out as follows:

BROWN =

L

 line

BLUE =

N

neutral

If not provided, connect a plug for the electrical load

indicated on the description label. Where a plug is provided,

the cooker hood must be installed in order that the plug is

easily accessible.

An omnipolar switch with a minimum aperture of 3mm

between contacts, in line with the electrical load and local

standards, must be placed between the appliance and the

network in the case of direct connection to the electrical

network.

•

The minimum distance between the support surfaces of the

cooking pots on the cooker top and the lowest part of the

cooker hood must be at least 65 cm.

If a connection tube composed of two parts is used, the upper

part must be placed outside the lower part.

Do not connect the cooker hood exhaust to the same

conductor used to circulate hot air or for evacuating fumes

from other appliances generated by other than an electrical

source.

Before proceeding with the assembly operations, remove the

anti-grease filter(s) (Fig.2

G

) so that the unit is easier to handle.

In the case of assembly of the appliance in the suction version

prepare the hole for evacuation of the air.

Installation:

To properly install the hood, proceed as follows:

1.  Fixing the cooker-hood to the lower part of a wall unit.

2.  Select method of operation (extraction or re-circulation).

Fitting the cooker-hood to the lower part of a wall unit.

The appliance should be embedded into the wall unit or

another support. This process should be carried out by using

4 screws suitable for the kind of unit following the instructions

for the drilling of the holes as shown in (Fig.1).

Exhausting Version:

With this type of installation the appliance discharges the

vapours externally outside the main wall or an existing exhaust

conductor. A non inflammable Ø 150 mm mural telescopic

tube (acceptable standard) is necessar y and should be

connected to the flange

B

 supplied (Fig.4).

Filter Version:

To transform the exhausting version to a filter version cooker

hood, active carbon filters are required and you should ask for

them from your local supplier.

The active carbon filters purify the air that is recycled within

the environment.
