19

English

2.   CHARCOAL FILTERS

These trap the odours present in the stream of air that passes through them. The air is puri-
fied by passing a number of times through the filters and being recirculated into the kitchen.
The charcoal filters cannot be cleaned, and should be replaced on average every 3-4 months
(according to use). To replace the charcoal filters, see the instructions in point H2.

3. CLEANING THE OUTSIDE OF THE APPLIANCE

It is advised to clean the external hood surfaces at least every 15 days in order to avoid that
oily or greasy substances affect the steel surfaces.

The ouside of the range hhod should be cleaned using a damp cloth and neutral liquid
detergent or denatured alcohol.

In case of fingerprint-less finish (fasteel) clean only with water and neutral soap using
clean with a soft cloth, rinse and wipe dry thoroughly. Do not use products that contain
abrasive substances, rough cloths or cloths specifically designed for cleaning steel. Using
abrasive substances or rough cloths will inevitably damage the finish of steel. The steel
surface will be irrevocably damaged if the instructions above are not complied with. Keep
these instructions together with the instructions for use of your hood.

The manufacturer accepts no liability for any damage caused by non-compliance with the
instructions above.

4.  CLEANING THE INSIDE OF THE APPLIANCE

The electrical parts or parts of the motor assembly inside the range hood must not be
cleaned using liquids or solvents.

  Do not use abrasive products.

All the above operations must be performed after having disconnected the appliance from the
mains power supply.

WARRANTY

M

The new equipment is covered by warranty.

The warranty conditions are provided by the distributor.

  The manufacturer is not liable for any inaccuracies in this booklet resulting from printing or

transcription errors. The manufacturer reserves the right to modify its products as it consid-
ers necessary or in the interests of the user, without compromising their essential safety and
operating characteristics.

N

HOOD ASSEMBLY INSTRUCTIONS

WARNING:

Failure to install the screws or fixing device in accordance with these instructions

may result in an electric shock hazard.

Phase 1

- Place the support bar (A-fig. 02) on the wall at a determined height from the cooker
by the sum of the heights X+374 mm.
- Use a spirit level to check the horizontal alignment and draw 2 marks at each end of the bar,

this is where the holes will be drilled.

- Drill the holes, insert 2 ø 8mm expansion bolts and fasten the bar with the relative screws.

Phase 2

- Hook the hood onto the support bar (fig. 03).
- Open the front glass panel and remove the metal filters.
- Adjust the alignment of the hood, using the fixing screws (Fig. 03). The upper screw (B)

adjusts the distance from the wall, the lower one (C) the vertical scrolling.
