Check deep-fryers during use: superheated oil may be flammable.
- Ensure there is adequate ventilation of the room when the rangehood is used at the same

time as appliances burning gas or other fuels.

- Do not flambe under the rangehood
- The exhaust air must not be discharged into a flue which is used for exhausting fumes from

appliances burning gas or other fuels.

- Ensure that all regulations concerning the discharge of exhaust air have been fulfilled before

you use the appliance.

  Before performing any cleaning or maintenance operations, disconnect the appliance by un-

plugging it or using the main switch. The manufacturer disclaims all liability for any damage
that may be directly or indirectly caused to people, things and animals due to the failure to
follow all the instructions provided in this booklet and above all the warnings relating to the
installation, operation and maintenance of the appliance.

WARRANTY

N

The new equipment is covered by warranty.

The warranty conditions are provided by the distributor.

  The manufacturer is not liable for any inaccuracies in this booklet resulting from printing or

transcription errors. The manufacturer reserves the right to modify its products as it consid-
ers necessary or in the interests of the user, without compromising their essential safety and
operating characteristics.

RANGE HOOD ASSEMBLY

O

(the assembly layout are indicative and valid for the 90 and the 140 with motors version)

Set the hole on the false ceiling, according to the indications of the drawings at the beginning
of the booklet. Fix the provided jig on the internal part of the false ceiling, so not to be visible,
to increase the reinforcement, as indicated in figure (OA-OB-OC).

Note:

if the MU is installed on the hood and on the FC flange connection and the plastic check valve
is used, it is recommended to install the latter on the conveyor outlet. The installation instruc-
tions are found inside the valve packaging.

ATTENTION, the false ceiling must be suitably reinforced to safely support the range hood.

Remove the AP openable panel and the metallic filters (see fig. 1).
Find installation type for outside exhaust version:

With motor unit (UM) (MU) fixed on the range hood:

1) Remove the FC flange assembled on the range hood and the FM flange assembled on the

UM (fig. 1). Define the direction of air outlet by rotating the FL flange of the motor unit (see
fig. 2). Fix UM to the range hood according to the output direction of the wanted air (see fig.
3).

2) Fix the safety chains to the ceiling using the provided screws and wedges (see fig. 4).
3) Lift the range hood near to the false ceiling: connect the UM (MU) motor outlet to the air

discharge duct using a flexible pipe. Carry out electric connection only after having discon-
nected the electric power supply powering the range hood. Introduce the safety chains
inside the made holes in the upper part of the range hood (fig. 5).

4) Place the hood in the false ceiling, which has been previously reinforced. When opened,

hooks G hold temporarily the hood to the false ceiling.

  Fasten all screws (B) by rotating them clockwise, so to open the hooks and block the hood

on the panel of the false ceiling.

  To remove the hood from the false ceiling, unfasten screws B by rotating them counter-
