23

By pressing one of the keys the led will illuminate and indicate the transmission of the code. If
the led does not illuminate, the battery may require replacing.

Replacing the battery: open the rear cover and insert the battery respecting the correct
polarity.

  ATTENTION! If the battery is replaced with one that is of the wrong type there is the possibi-

lity of an explosion.

When discharging the battery, follow the respective regulations that are currently in force.
The manufacturer

Falmec S.p.A. - Via dell’Artigianato, 42 - 31029 Vittorio Veneto (TV) ITALY

declares that this radio control conforms to all of the technical regulations related to the pro-
duct and within the application confines of the directive 1999/5/CE.

All of the necessary radio frequency tests have been performed.
ETSI EN 300 220-2 V2.1.2 (2007-06)

EN 60950-1 (2001)

ETSI EN 301 489-1 V1.4.1 (2002)

EN 50371 (2004-06)

ETSI EN 301 489-3 V1.4.1 (2002)

INSTRUCTION FOR CHANGING THE FALMEC RADIO CONTROL

(to be used only

in the case of malfunction due to interferences)

Disconnect the device from the mains.
To enter in the “change code mode” the button “Luce” and “Timer” (remote control) must
be pressed together for more than 3 seconds. After 3 seconds the LED starts flashing slowly.
Now, if you press the button “-“ (remote control) within 5 seconds a new code is generated in
casual mode and memorized within the radio control. The memorizing is confirmed by 3 quick
LED flashings.
To get back to the default code: press “-“ and “+” (remote control), together for more than 5
seconds. After 5 seconds, the default code is memorized within the radio control. The memo-
rizing is confirmed by 3 quick LED flashings. Plug the device to the mains and check that lights
and motors are off. Press the timer button on the push-button panel for 2 seconds and, when
the red LED lights up, press any of the radio control’s buttons within 10 seconds. With this
operation a new transmission code is registered.

METALLIC FILTERS AND CARBON FILTER

H

1.   METAL FILTERS

To access the metallic filters open the AP panel (see fig. 1). To remove the grease-trapping
metallic filter pull on the handle.

2.   CHARCOAL FILTERS

Hood not designed for charcoal filters.

LIGHTING

ASSEMBLY AND REPLACEMENT

I

FLUORESCENT TUBE

(Section reserved for qualified installers)

Replacing the fluorescent tube (fig. 8):
a)  Disconnect the device from the mains;
