13

Deviation for Germany:
When the range hood and appliances supplied with energy other than electricity are simulta-
neously in operation, the negative pressure in the room must not exceed 4 Pa (4x10 E-5 bar).

F

HOOD VERSION WITH INTERNAL RECIRCULA-
TION (filtering)

In this model, the area passes through the carbon filters to be purified and is then introduced
into the kitchen environment. To mount the filters, refer to section H2.

G

OPERATION

1: TIMER - FILTER RESET - SHUTTER OPENING - SHUTTER CLOSING
Timer:

With the motor running, pressing this key will enable timed motor shut-down after 15 min-
utes. At the end of the 15 minutes the motor and the light will switch off and the mobile part
will close back up. The red LED flashes to indicate that the function is enabled. Varying the
speed of the motor will not interrupt the count. If the motor is stopped using key 4, the func-
tion will automatically switch off. When the timer function is enabled, it is possible to switch
it off by pressing key 1.

Filter Reset:

Every 30 hours of extractor fan operation, the filter signal will light up (steady red light).

With the motor and light switched off, holding down key T1 will delete the signal and the
shutter will open providing access to the filters. In this state it is not possible to start the
motor and keys T2..T5 are disabled. Once the filters are put back in place, holding down key
T1 will close the shutter and keys T2..T5 will start working again.

Opening the mobile part:

When all of the leds are off (light and motor off) holding down this key allows

you to open the mobile part of the hood so that maintenance can be carried out. During this
state it is not possible to turn the motor on, keys T2..T5 are disabled.  Key T1 is on.

Closing the mobile part:

To exit the state where the mobile part is open and the is motor off, hold

down key T1. The red T1 signal switches off and the T2..T5 keys will start working again at
this time.

2: RECIRCULATION FUNCTION
Recirculation Function:

When the motor is off, holding down key T2 will turn on the recirculation func-

tion, and the mobile part will open. Key T2 will flash. During the recirculation function (lasting
24 hours) the hood will stay on for 1 hour at the 1° (1st) speed, then it will stop for 3 hours and
switch back on for another hour. These cycles are repeated until timeout.

When this function is enabled, other speeds may not be selected. To switch this function off,
hold the T2 key down for at least 3 seconds. When the recirculation function is on the shutter
stays open regardless of whether the motor is on / off.

3: DECREASE IN FAN SPEED

By pressing this key the motor will slow to the first speed.

4: FAN ON/OFF

Pressing this key turns the fan on/off at the same time as the shutter opens/closes. The
