22

FILTERS

REMOVING AND REPLACING’S INSTRUCTIONS

H

1.  METAL FILTERS

To access the metal filters, open the perimetral exhaust panel as described
in Fig. H and then act on handle A.

A

2.  CHARCOAL FILTERS

To replace the charcoal filters, proceed as follows: remove the metal filters
as described above. The two filters located at the ends of the motor can now
be easily accessed.

To install the new fi lters see picture.

In case of hood with the motor box the fi lter is located on the botton part of
the motor box.

To install the new fi lters see picture.

To order new charcoal fi lters contact the distributor/retailer.

VALID ONLY FOR ITALY:

 download the appropriate order form from: www.

falmec.com (access the assistance drop-down menu).

LIGHTING

ASSEMBLY AND REPLACEMENT

I

SPOTLIGHT

How to replace a square halogen light:
a)  Check that the equipment is disconnected from the power supply.
b)

Open the panel completely till 90° (see figure)

 pressing the PUSH button

c)  Replace the lamp with a similar one (halogen, max 20 W, 12 Volt, G4 con-

nection).

d) Close the panel. If the panel does not close correctly repeat the operation at

point b.
