25

Maintenance of the remote control

Cleaning the remote control:

Clean the remote control with a damp cloth and a neutral
solution of detergent without abrasive substances.


Changing the battery:

•

Open the battery casing.

•  Replace the flat batteries with 3 new 1.5 V type AAA

batteries.

Respect the polarity indicated in the battery casing when
inserting the new battery!

•

Close the battery casing up again.

Disposal of the batteries

Ultimate disposal of the batteries should be handled according
to all national laws and regulations. Do not place used
batteries in your regular waste.
Ultimate disposal of the batteries must be done safely

.

Contact your local waste management officials for other
information regarding the environmentally sound collection,
recycling, and disposal of the batteries.


Maintenance

ATTENTION!

Before performing any maintenance operation,

isolate the hood from the electrical supply by switching off at
the connector and removing the connector fuse.
Or if the appliance has been connected through a plug and
socket, then the plug must be removed from the socket.

Cleaning

The cooker hood should be cleaned regularly (at least with the
same frequency with which you carry out maintenance of the
fat filters) internally and externally.  Clean using

ONLY

 the

cloth dampened with neutral liquid detergent.

DO NOT

CLEAN WITH TOOLS OR INSTRUMENTS

. Do not use

abrasive products.

DO NOT USE ALCOHOL!

Warning!

 Failure to carry out the basic cleaning

recommendations of the cooker hood and replacement of the
filters may cause fire risks.
Therefore, we recommend observing these instructions.
The manufacturer declines all responsibility for any damage to
the motor or any fire damage linked to inappropriate
maintenance or failure to observe the above safety
recommendations.

Grease filter -

Fig. 10-27

Traps cooking grease particles.

This must be cleaned once a month (or when the filter
saturation indication system – if envisaged on the model in
possession – indicates this necessity)  using non aggressive
detergents, either by hand or in the dishwasher, which must
be set to a low temperature and a short cycle.
When washed in a dishwasher, the grease filter may discolour
slightly, but this does not affect its filtering capacity.
To remove the grease filter, pull the spring release handle.

Charcoal filter (filter version only) -

Fig. 26

It absorbs unpleasant odours caused by cooking.

The activated charcoal filter can be one of these types:

•

Washable activated charcoal filter.

•

NON-washable activated charcoal filter.

Washable activated charcoal filter

The charcoal filter can be washed once every two months
using hot water and a suitable detergent, or in a dishwasher at
65°C (if the dishwasher is used, select the full cycle function
and leave dishes out).
Eliminate excess water without damaging the filter, then
remove the mattress located inside the plastic frame and put it
in the oven for 10 minutes at 100° C to dry completely.
Replace the mattress every 3 years and when the cloth is
damaged.

NON-washable activated charcoal filter

The saturation of the

charcoal filter

 occurs after more or less

prolonged use, depending on the type of cooking and the
regularity of cleaning of the grease filter.
In any case it is necessary to replace the cartridge at least
every four mounths.
The charcoal filter may NOT be washed or regenerated.

Assembly

Hook the charcoal filter at the back on the metal tongue of the
hood first, then on the front with the two knobs.

Disassembly

Remove the charcoal filter by turning the knobs fixing it to the
hood by 90°.

Replacing lamps -

Fig. 28

The hood is equipped with a lighting system based on LED
technology.
The LEDs guarantee an optimum lighting, a duration up to 10
times as long as the traditional lamps and allow to save 90%
electrical energy.
To purchase spare LEDs, contact the technical assistance
service.
