19

Maintenance

Cleaning

Clean using

ONLY

 the cloth dampened with neutral liquid

detergent.

DO NOT CLEAN WITH TOOLS OR

INSTRUMENTS

. Do not use abrasive products.

DO NOT USE

ALCOHOL!

Panel

Fig. 8
Attention! Hold the panel with both hands when
dismantling and re-mounting in position to avoid it falling
and causing damage to people or things.
Dismantling:

-pull the panel (FRONT SIDE) downward with decision,
-push to the left the small lever located on the right side of the

panel,

-unhook it from the back hinges.

Cleaning:

Clean the suction panel with the same frequency as the fats
filter using a cloth soaked in neutral liquid detergents.
 Avoid the use of products containing abrasives. DO NOT
USE ALCOHOLS.

Montage:

The panel must be hooked at the back and fixed in front fitted
into the pins for the purpose on the surface of the hood.

Attention!

always check that the panel is well fixed in its

place.

Grease filter

Fig. 1-7
Traps cooking grease particles.

The grease filter

 must be cleaned once a month using non

aggressive detergents, either by hand or in the dishwasher,
which must be set to a low temperature and a short cycle.
When washed in a dishwasher, the grease filter may discolour
slightly, but this does not affect its filtering capacity.
To remove the grease filter, pull the spring release handle.

Charcoal filter (filter version only)

Fig. 6
It absorbs unpleasant odours caused by cooking.

The saturation of the

charcoal filter

 occurs after more or less

prolonged use, depending on the type of cooking and the
regularity of cleaning of the grease filter.
In any case it is necessary to replace the cartridge at least
every four months.
The charcoal filter may NOT be washed or regenerated.

Circular carbon filter

Apply one on each side as cover to both the shield grids of the
motor impeller, then turn clockwise.
For the disassembly, turn counter-clockwise.

Replacing lamps

Fig. 9

Disconnect the appliance from the electricity.

Warning!

Prior to touching the light bulbs ensure they are

cooled down.
Replace the old light bulb with the one of the same type as
specified in the feature label or near the light lamp on the
hood.

1.

  Using a flat head screwdriver or equivalent tool, carefully

pry loose the light cover.

2.

  Remove the damaged light and replace with a new 12

Volt, 20 Watt (Maximum) halogen light made for a G-4
base SUITABLE FOR USE IN OPEN LUMINAIRES.
Follow package directions and do not touch new light
with bare hands.

3.

  Reinstall the light  cover. (it will snap shut).

If the lights do not work, make sure that the lamps are fitted
properly into their housings before you call for technical
assistance.

- Model with LED light

The hood is equipped with a lighting system based on LED
technology.
The LEDs guarantee an optimum lighting, a duration up to 10
times as long as the traditional lamps and allow to save 90%
electrical energy.

For replacement, contact the technical service.
