INSTALLATION

ELECTRICAL CONNECTION

During installation and maintenance ope-
rations, the appliance must be disconnec-
ted from the mains; fuses must be
isolated or removed.
The electrical connections should be
made before the appliance is installed in
its housing.
Check that:

- the electrical installation is sufficiently

rated,

- the supply wires are in good condition,
- the diameter of the wires complies with

the installation requirements.

This appliance is supplied fitted with a
3-core (phase, neutral and earth)
0.75mm

2

H 05 VVF cable. It must be

connected to a 220-240V single phase
mains network via an IEC 60083 socket
which must remain accessible after ins-
tallation, in accordance with the installa-
tion rules.
The fuse in your installation must be 10
or 16A. If the mains cable is damaged,
call after-sales service and so avoid any
danger.
If the electrical installation in your home
requires any changes in order to connect
your appliance, contact a professional
electrician.
If the hood malfunctions in any way, un-
plug it or remove the fuse for the circuit
concerned.

The installation must comply with current
regulations for the ventilation of rooms. In
particular, air must not be evacuated into
a duct used to evacuate fumes from ap-
pliances using gas or other fuels. Disused
ducts may only be brought into service, if
approved by a competent specialist. The

evacuation line, whatever its type, must
not emerge in a loft space

.

2.1 - USE IN EVACUATION MODE

You have a duct that leads outside.
Your hood may be connected to it via an
evacuation duct (minimum 125mm dia.,
made of enamelled, aluminium hose or
other non-flammable material). If your
duct is less than 125mm in diameter, you
must change to recycling mode.

2.2 - USE IN RECYCLING MODE

You do not have a duct leading to the out-
side.
All our appliances can operate in recy-
cling mode.
In such a case, purchase a recycling kit
comprising a set of active carbon filters
and a deflector.

Energy saving advice

To obtain the best performance from your
appliance, limit the number of bends and
length of the duct as much as possible.

To simplify the installation of your hood,
we have designed a two-step fitting sys-
tem, comprising:

1) Fitting the motor bracket.
2) Assembling the hood body and the

chimney.

2

.3 - FITTING  THE HOOD

The minimum distance between the coo-
king surface (2.3) and the lowest part of
the hood is 65cm. If the instructions for a
hob installed below the hood specify a
distance greater than 65 cm, then that
distance must be applied.

- Draw a horizontal line (A) at least 65cm

above the cooking surface.
