F

ixing the hood to the lower part of the wall cabinet:

This type of appliance must be fitted inside a cabinet or in-

side another type of support structure. To fix it in place, use

4 screws which are suitable for the type of cabinet, making

holes in accordance with the diagram shown in (Fig.1). To fit

the appliance correctly, align the front panel of the cooker

hood with the cabinet door and adjust spacer

L

 using screws

P

(Fig.2), then ensure the appliance meets the cabinet at the rear.

•  Extraction through an outside wall:

The appliance expels the fumes through an outside wall or

a duct. It is necessary to buy a telescopic pipe in accordance

with the standards in use (inflammable) and connect it to

flange

H

 (Fig.3A).

•  Recirculation:

To transform the cooker hood from the extraction version to

the re circulating one ask your supplier for an activated carbon

filter. The filter must be fitted to the extracting group cooker

hood in the centre of the fan grille by twisting it by 90 degrees

until it is gripped securely (Fig.5). For this operation remove the

anti-grease filter(s)

G

 (Fig.4). The clean air is returned into the

room through a connecting tube passing inside the cupboard

and connected to the ring

H

 (Fig.3B).

  USE AND MAINTENANCE

•

We recommend that the cooker hood is switched on before

any food is cooked. We also recommend that the appliance is

left running for 15 minutes after the food is cooked, in order

to thoroughly eliminate all contaminated air.

The effective performance of the cooker hood depends on

constant maintenance; the anti-grease filter and the active

carbon filter both require special attention.

•  The  anti-grease  filter

 is responsible retaining the grease

particles suspended in the air, therefore it is subject to clog-

ging with variable frequency according to the use of the

appliance.

-  To prevent the danger of possible fires, at least every 2

months one must wash the anti-grease filters by hand using

non-abrasive neutral liquid detergents or in the dishwasher

at low temperatures and on short cycles.

-  After a few washes, colour alterations may occur. This does

not give the right to claim their replacement.

•  The active carbon filters

 are used to purify the air that is

sent back into the room and its function is to mitigate the

unpleasant odours produced by cooking.

-  The non-regenerable active carbon filters must be replaced

at least every 4 months. The saturation of the active charcoal

depends on the more or less prolonged use of the appliance,

on the type of kitchen and on the frequency with which anti-

grease filter is cleaned.

-  Regenerable active charcoal filters must be washed by hand,

with non abrasive neutral detergents, or in the dishwasher at

a maximum temperature of 65°C (the washing cycle must be

complete without dishware). Remove excess water without

damaging the filter, remove the plastic parts, and let the mat

dry in the oven for at least 15 minutes approximately at a

maximum temperature of 100°C. To keep the regenerable

charcoal filter functioning efficient this operation must be

repeated every 2 months. These must be replaced at least

every 3 years or when the mat is damaged.

•  Before remounting the anti-grease filters and the regen

-

erable active charcoal filters it is important that they are

completely dry.

•  Clean  the  hood  frequently,  both  internally  and  exter

-

nally, using a cloth dampened with denatured alcohol or

neutral liquid detergents that are non abrasive.

•

The lighting .system is designed for use during cooking

and not for the prolonged general lighting of the room. The

prolonged use of the lighting system significantly decreases

the average duration of the bulbs.

•

If the appliance is equipped with courtesy lights it is possible

to use them for general room lighting for a prolonged amount

of time.

•  Attention:

 the non compliance with the hood cleaning

warnings and with the replacement and cleaning of the filters

entails risk of fires. One therefore recommends keeping to the

suggested instructions.

•  Replacing halogen light bulbs (Fig.6):

To replace the halogen light bulbs

B

, remove the glass pane

C

 using a lever action on the relevant cracks.

Replace the bulbs with new ones of the same type.

Caution:

 do not touch the light bulb with bare hands.

•  Commands  slider

(Fig.7)

the key symbols are explained

below:

A

=

 Light switch

A1 =

 Off key

A2 =

 On key

B    =

Speed control

B1   =

Off key

B2   =

 FIRST SPEED key

B3   =

 SECOND SPEED key

B4   =

 THIRD SPEED key

C    =

Gemma warning light key.

•  Replacing the halogen/incandescent lamps (Fig.8):

Only use lamps of the same type and wattage installed on

the device.

CUSTOMER ASSISTANCE SERVICE

Before contacting the Technical Assistance Service.

If the product does not operate at all, we advise you to:

-   Check that the plug has been inserted into the power socket

correctly.

If you cannot identify the cause of the operating anomaly:

switch off the appliance (do not subject it to rough treatment)

and contact the Assistance Service.

PRODUCT SERIAL NUMBER. Where can I find it?

It is important that you inform the Assistance Service of your

product code and its serial number (a 16-character code which

begins with the number 3); this can be found on the guarantee

certificate or on the data plate located inside the appliance.

This will help to avoid wasted journeys being made by techni-

cians, thereby (and most significantly) saving the correspond-

ing callout charges.

THE MANUFACTURER DECLINES ALL RESPONSIBILITY

FOR EVENTUAL DAMAGES CAUSED BY BREACHING THE

ABOVE WARNINGS.
