15
3.
Mount the heater on the wall in its predetermined place, straight and level, with the water inlets
and outlets facing downwards. To do so, mark the 4 spots for the holes on the wall and drill the
holes using a 6 mm drill; place the enclosed splay-winged, plastic pins ("dibbles") into each
hole and connect the heater firmly to the wall using the 4 enclosed screws.
4.
Join the water inlet pipe to the water heater and be sure that there are no leakages. In the water
heater of the type "VEGA" do not set up a valve at the water outlet or any other shut off
devices.
5.
The water heater is connected to a separate three conductor round cable with the diameter 4
mm. and fixed automatic load control for 25 amperes. The threads of the wire are connected
according to the colors. Watch carefully! A yellow grounding wire must be connected right and
sharply. It is very important to use special heat resistant conductors because the temperature
can be higher than 50 Celsius above zero.
6.
The water heater is connected to a single phase power supply through the double -contact
switch. The following switch is set separately from the water heater. The water heater must
have a very strong grounding, the grounding lead must be painted in a definite color not to mix
with the other leads.
7.
A protective cutout device is to be installed to the power-supply circuit. Please
contact an authorized specialist.
ATTENTION PLEASE! First you should fill in the vacuum bottle with the water, the
water heater is full when the water will flow continuously from the shower, and only then
switch the water heater on. If you do not do this, the heating unit can blast or the plastic
parts can be burnt or the appliance can stop working.
8.
Check how the water heater works by letting the water run through it.
9.
Put the cover on the back part of the water heater and fix it with 4 screws after you make sure
that there is no leakage, and the electric circuit is working correct. The cover installation should
be made in the following way: there are two switches under the cover, at the bottom part of
each switch there is a rectangle with an open side. It is necessary to turn it upwards. There are
two pins in the base. Each of them has got a skew lever, one side of which is larger than the
other. Please turn the larger side upwards. After that, please put the cover on the base.
10.
It is forbidden to input the water with temperature above 35
o
C; it may cause the overheating of
outlet water to level above 95
o
C.
ATTENTION PLEASE! It is forbidden to switch on the appliance when there is a danger
for the freezing of the water in the water heater.
Accessories
Model
Accessories
Shower
Flexible pipe
1,5
м
Bracket
Set of
rubber
gaskets
"S" for
kitchen
VEGA T
5.5
shower
+
+
+
+
sink
+
+
combined
+
+
+ +
+
Additionally should be bought:
an electric wire, a regular tap, a hose for the connection to the cold
water pipe.
