EN

12

1. PRODUCT MOUNTING

See “General Warnings” N°.1 to N°.6

For product installation, refer to drawings section 2 page 3 to page 6.

2. HYDRAULIC CONNECTION

See “General Warnings” N°.10 to N°.14

For hydraulic connection, refer to drawings section 4 page 8.


-   It is necessary to clean the supply piping prior to the hydraulic connection. The connection to the hot

  water outlet is to be carried out with a cast iron or steel sleeve or a dielectric connector, to avoid

  corrosion of the pipe (direct contact iron / copper). The use of brass fi ttings is prohibited.

-  Always install a new safety device on the cold water pipe of the water heater, which comply with

  the standards (EN 1487 in Europe), with a pressure of 0.7 or 0.9 MPa (7 or 9 bars) according

  to the nominal pressure, with diameter adapt : 1/2» or 3/4” according with the range of product.

 -

CAUTION

: Do not use the safety valve included in this packaging in France (home country and French

overseas)

3. ELECTRICAL CONNECTION

For electrical connection, refer to drawings section 4 page 8.


-  The water heater can be connected and operated only on AC 230V. Connect the heater with a rigid

  cable with conductors 2,5mm². Use a standardised channeling (rigid or fl exible conduit) until

  the calibrated housing cover.

-  Directly connect devices with a cable or plug. In France, a product with plug is strictly prohibited

  and cannot be sold and installed.

-  Always connect the earth conductor of the cable to the earth ground wire or connect the earth

  conductor to the appropriate terminal identifi ed by the symbol . This connection is compulsory for

  safety reasons. The earth wire green - yellow must be longer than those of phases. The installation

  must be equipped, upstream of the appliance, with a bipolar cut-out device (minimum contact

  distance of 3 mm fuse, breaker switch). In the case where hydraulic connexions are in insulated

  material, electrical circuits shall be protected by a differential circuit breaker 30 mA adapted to local

standards.

Thermal circuit breaker

(see drawings section 4 page 8): All our products are equipped with a thermostat

with thermal circuit breaker and manual resetting which cuts off the power supply to the water heater

in case of overheating. If the safety trips:

²

 switch off the power before taking any further action,

²

 remove the cover,

²

 check the electrical connections,

²

 reset the thermal circuit breaker

If the circuit breaker keeps tripping, replace the thermostat. Never short circuit the safety cut out or

the thermostat. Connect the power supply only via the terminal.

INSTALLATION
