EN

15

compliance with current safety standards, which is adequate for the maximum power absorbed by the water heater

(refer to the data plate) and that the section of the cables for the electrical connection is suitable and complies with

local regulations. The manufacturer is not liable for damage caused by lack of grounding or anomalous power

supply. Before starting up the appliance, check that the power rating matches that given on the nameplate.

The use of multiplugs, extensions or adaptors is strictly prohibited.

It is strictly forbidden to use the piping from the plumbing, heating and gas systems for the appliance earthing

connection. If the appliance is supplied with a power supply cable, should the latter need replacing, use a cable

featuring the same characteristics (type H05VV-F 3x1 mm

2

, 8.5 mm in diameter. The power cord (type H05VV-F

3x1 mm

2

 dim. 8.5 mm) must be routed into the hole (

F

 Fig. 3) in the back of the appliance and connected to the

thermostat terminals (

M

 Fig. 6)

Use a two-pole switch conforming with national laws in force (contact gap of at least 3 mm, preferably equipped with

fuses) to disconnect the appliance's power supply.

The appliance must be grounded with a cable (yellow/green and longer than the phase cable) connected to the

terminals marked   (

T

 Fig. 6).

Before starting up the appliance, check that the power rating matches that given on the nameplate. If the appli-

ance is not supplied with a power supply cable, choose one of the following installation modes:

-   connection to mains with a rigid pipe (if the appliance has no cable clamp); use a cable with a minimum 3x1 mm

2

section;

-   with a flexible cable (type H05VV-F 3x1 mm

2

, 8.5 mm in diameter) if the appliance is supplied with a cable clamp.

Testing and ignition of the device

Before powering up the appliance, fill the heater with mains water.

To do so, open the mains cock and the hot water tap until all the air has been vented from the boiler. Check for

leaks from the flanges, tighten down the fittings (not too much!) if necessary.

Turn on the appliance with the switch.

MAINTENANCE REGULATIONS (for qualified personnel)

Before calling your Technical Servicing Centre, check that the fault is not due to lack of water or power failure.

Caution

: disconnect the appliance from the mains before conducting any maintenance work.

Emptying the appliance

The appliance must be emptied if it is to be left unused for a long period and/or in premises subject to frost.

To drain the appliance, proceed as follows:

-   close the tap, if installed (

D

 Fig. 1), otherwise the central tap domestic power supply;

-   turn on the hot water tap (wash basin or bathtub);

-   open the drain valve

B

 (Fig. 1).

Replacing parts

Remove the cover to access the electrical parts.

Access the thermostat by disconnecting the power cable and lamp cables, then remove it from its seat.

Before handling the heating element and anode, empty the appliance.

Undo the 4 bolts (

A

 fig. 4) and remove the flange. The heating element and anode are attached to the flange.

During reassembly, make sure that the flange gasket, the thermostat and the heating element are put back in

their original positions.

We recommend replacing the flange gasket (

Z

 Fig. 5) every time it is disassembled.

Use only original parts from authorized service centres authorized by the manufacturer.

Periodical maintenance

The heating element (

R

 fig. 5) should be descaled every two years (the frequency must be increased, if water

is very hard) to ensure it works properly. If you do not wish to use a liquid descaler (in this case please read the

safety data sheets of descaling), you can simply break off the deposit, taking care not to damage the heating

element's cladding. The magnesium anode (

N

 fig. 5) must be replaced every two years, otherwise the decay of

the warranty. In the presence of aggressive or waters rich in chloride it is recommended to check the status of

the anode annually.

To remove this, disassemble the heating element and unscrew from the support bracket.

Bipolar safety device

If the water overheats excessively, a safety circuit breaker (compliant with applicable national regulations) trips
