FN-1608RW ASSEMBLY:

The fan is delivered unassembled. Before starting assembly, make sure that

the delivery is complete and that the parts are intact.

1.  Attach the leg (12) with the screws (13) to the base (14).

2.  The telescopic tube consists of two parts: the main part (12) and the

extension (9) inside the main part (12). Both parts are locked with a clamp

(10) clockwise (to the right). Unscrew the clamp (10) counterclockwise (to

the left), pull out the telescopic tube extension (9) to the required length,

then screw it back with the clamp (10).

3.  Slide on and screw (8) the fan motor (7) onto the top of the tube (9).

4.  Unscrew the blade screw (3) by turning clockwise and the nut (5) by

turning counterclockwise from the motor shaft (if the blade screw & the

nut are already installed).

5.  Slide the rear protective guard (6) on the body and secure with the ring (5)

by turning it clockwise. Make sure that the tabs on the fan line up with the

holes in the guard and that the carrying handle is on top.

6.  Slide the blades (4) onto the motor shaft, connecting the slots at the base

of the blades with the projections on the shaft, and secure them with the

blade screw (3) by turning counterclockwise.

7.  Use the screws to attach the decorative cover (1) to the front protective

guard (2).

8.  Slide on the front protective guard (2), securing it to the rear protective

guard (6) with the clips.
