11

• TOUCH CONTROL

(Fig. 7)

A

F

E

B

C

D

E

G

H

C

D

A.

On/Off

 key

B.

Lock

key

C.

Zone

[+]

 key (increase power)

D.

Zone

[-]

 key (decrease power)

E.

Cooking Zone Display

F.

Timer Display

G.

Timer

[+]

 key (increase value)

H.

Timer

[-]

 key (decrease value)

• SWITCHING THE APPLIANCE ON

Press the

On-Off

 key to switch the hob on.

All the displays relative to the cooking zones

switch on in the «

0

» standby position.

The control unit remains active for

10

seconds.

If no cooking zone is selected

within this time, the appliance switches off

automatically.

• SWITCHING A COOKING ZONE ON

Select the desired cooking zone and press

one of the

Zone

[+]

 keys.

Press the

Zone

[-]

key to go to position 9

(max. power) or

Zone

[+]

key

to go to position

1 (min. power). Once this operation has been

completed you can adjust the temperature

with the

Zone

[+]

and

 [-]

keys.  The power

of the single cooking zone can be adjusted

in

9

 different positions and will be shown on

the relative luminous display with a level from

«

1

» to «

9

».

• POT DETECTION

« »

This cooktop is fitted with an interactive

control system that makes it very easy and

comfortable to use. If the cookware is removed

from an active cooking zone, the display

shows the symbol « » which disappear when

the cookware is repositioned on the cooking

zone, continuing with the previous settings.

After use, always bring power to «

0

»

(do not

leave on the symbol

« »

).

The symbol «

» also appears on one of the cooking zones

displays when:

1)The recipient being used is not suitable for

induction cooking.

2)The diameter of the recipient used is inferior

to that allowed by the appliance.

• RESIDUAL HEAT

 «

H

»

If the temperature of the cooking zone is still

high (over

50

°) after it has been switched off,

the relative display will indicate the «

H

» symbol

(residual heat). The symbol will only switch off

when the burn risk in no longer present.

• QUICK HEATING/POWER BOOST

«

P

»

This function further reduces cooking time

of a given area taking the temperature to the

maximum power for a

10

minute interval.

At the end of this interval, the cooking area

power automatically returns to level «

9

».

The use of this function is indicated for the

short time heating of large quantities of liquid

(eg. water for cooking pasta) or dishes.

To activate this function, select the cooking

zone and press the

Zone

[+]

 key up to level

«

9

». Press the

Zone

[+]

 key again.

An acoustic signal will be emitted and the

symbol «

P

» will be shown on the relative

Cooking Zone display.

• TIMER

This function allows establishing the time

(from «

01

» to «

99

» minutes) for automatically

switching the selected cooking zone off.

Switch on at least one cooking zone and

adjust the temperature. Press simultaneously

the

Timer [+]

 and

[-]

 keys to enter the timer

function.

Press again the

Timer  [+]

 and

[-]

keys simoultaneously to select the cooking

zone on which you want to activate the timer.

The selected cooking zone will be indicated

by a flashing led located on one of the corners

of the

Timer Display

.

Set the auto switching off time by pressing

the

Timer [+]

 or

Timer [-]

 key. The cooking

zone on which the timer has been activated

is indicated by a steady led at one of  the

corners of the Timer Display.

An acoustic signal will indicate the timer

expiration and the relative cooking zone will

automatically switch off.  Press any of the

keys to stop the acoustic signal.
