Type of cooker
Type of cooker
Dimensions
Dimensions
Cookers with gas compartment only
Electric powered cookers up to 1000 W
Electric powered cookers with more than 1000 W power
Cookers with gas compartment only
Electric powered cookers up to 1000 W
Electric powered cookers with more than 1000 W power
3 X 0.50 mm²
3 X 0.75 mm²
3 X 1.5 mm²
3 X 0.50 mm²
3 X 0.75 mm²
3 X 1.5 mm²
Exhaustion of the combusted gases
Combusted gases shall be exhausted by using a paddle box with a chimney.
If a paddle box is not used, then an electrical fan which will be installed on the outside wall or
window of the kitchen shall be used and it shall ensure that it will be capable of exhaustin at least 3
5 times more air than the volume of the kitchen.
Components which are shown in figure 14 are:
А:
Ventilation hole
С:
Paddle box with chimney
Е:
Electric powered fan
Gas connection
Make sure that local gas supply system is in compliance with the equipment. In order to
make this, you can make use of the label on the equipment and table in the user's guide.
Gas connection must be performed by qualified personnel while following the present
directives.
If metal pipes are used for connection, make sure that it won't contact with a moveable part or
it won't sustain
a shock.
Complete the connection wihout causing any pressure on the equipment. Gas connection valve
has G½" knurls
on it.
Use soap and water in order to test the possible gas leakage after you complete the
connection.
Electrical Connection
Before making the electrical connections of the equipment, make sure that voltage and power
cables are in compliance with the values shown on the label located on the equipment.
If the equipment will be connected to the main electricity network directly, a circuit breaker with a
contact distance of minimum 3 mm and which is in compliance with the equipment load and
standards shall be used.
·
Since it may cause external heating and fire, do not use reductors, adaptors and
switches for the electrical connection.
·
Always connect the power cable to a grounded socket. Manufacturer states that he
will not be responsible from any matters that may occur if this rule is not followed.
o
If the power cable is needed to be replaced, a heat resistant cable (T90C) which can cope
with the equipment load and which has the same standards used by the manufacturer shall be
used. This cable can be provided from authorized services. In addition, there shall be a yellow
green grounding connection, which is 20 mm longer than the others, at the end of the power
cable that will be connected on the equipment.
Please refer to the following cable for the dimensions of the power cable.
Exhaustion of the combusted gases
Gas connection
Make sure that local gas supply system is in compliance with the equipment. In order to
make this, you can make use of the label on the equipment and table in the user's guide.
Use soap and water in order to test the possible gas leakage after you complete the
connection.
Electrical Connection
Since it may cause external heating and fire, do not use reductors, adaptors and
switches for the electrical connection.
Always connect the power cable to a grounded socket. Manufacturer states that he
will not be responsible from any matters that may occur if this rule is not followed.
Combusted gases shall be exhausted by using a paddle box with a chimney.
If a paddle box is not used, then an electrical fan which will be installed on the outside wall or
window of the kitchen shall be used and it shall ensure that it will be capable of exhaustin at least 3
5 times more air than the volume of the kitchen.
Components which are shown in figure 14 are:
Ventilation hole
Paddle box with chimney
Electric powered fan
Gas connection must be performed by qualified personnel while following the present
directives.
If metal pipes are used for connection, make sure that it won't contact with a moveable part or
it won't sustain
a shock.
Complete the connection wihout causing any pressure on the equipment. Gas connection valve
has G½" knurls
on it.
Before making the electrical connections of the equipment, make sure that voltage and power
cables are in compliance with the values shown on the label located on the equipment.
If the equipment will be connected to the main electricity network directly, a circuit breaker with a
contact distance of minimum 3 mm and which is in compliance with the equipment load and
standards shall be used.
If the power cable is needed to be replaced, a heat resistant cable (T90C) which can cope
with the equipment load and which has the same standards used by the manufacturer shall be
used. This cable can be provided from authorized services. In addition, there shall be a yellow
green grounding connection, which is 20 mm longer than the others, at the end of the power
cable that will be connected on the equipment.
Please refer to the following cable for the dimensions of the power cable.
А:
С:
Е:
·
·
o
7
7
