“H” instead of “=”. The lower right corner of all cooking point displays flash at one-second
intervals to indicate that no cooking areas has been selected at the time.
After switching ON the electric control remains activated for 20 seconds. If no cooking
zone or timer selection follows within this period of time, the electronic control automatically
switches back into the stand-by mode.
The control can only be switched ON if it identifies the ON/OFF key alone being operated.
Should it recognize key activation other than that, the control remains in the stand-by mode.
If the child safety feature is active when switching on, all cooking zones show “L” (LOCKED).
If the cooking zones are in a “hot” status, the display shows “L” and “H” in alternation.
When the Touch Control is ON it can be switched OFF at any time by operating the ON/OFF
key. This is also valid if the control has been locked (activated child safety feature).
The ON/OFF key has always priority in the switch-OFF function.

Automatic switch-OFF

When the control is ON it automatically switches OFF after 20 seconds if no cooking zone or
select key has been operated within this period of time. In the case of a cooking selection, the
automatic switch-OFF time is composed of 10 seconds deselection time for a cooking zone at
setting “0” and 10 seconds switch-OFF time.

Hob zone On/Off

With the Touch Control on, a hob zone can be selected by touching the dedicated display (6).
The corresponding display them shows the fixed spot on the display and “0” rather than “H” –
for very hot hob zones. The spots disappear on the display for all other hob zones.
At this point the cooking level can be selected by means of the Slider. In this way the
corresponding hob zone is activated. The maximum and minimum values are “9” (to the right)
and “0” (to the left).

Turning a single hob zone off

A single hob zone can be turned off by selecting a cooking level [0]. If a hot hob zone warning
light is on [H], this signal is alternately displayed with [0] and simultaneously with the spot on
the display.
Once the Touch Control is turned off, the display remains black or the symbol [H] is displayed
as a warning of a hot hob zone.
Switching OFF all cooking zones
Immediate switching OFF of all cooking zones can be achieved anytime by means of the ON/
OFF key. Once the Touch Control is switched off, the display remains off or the system [H] is
displayed as a warning that the cooking area is hot.

Switching OFF all cooking zones

Immediate switching OFF of all cooking zones can be achieved anytime by means of the
ON/OFF key. In the stand-by mode, an “H” appears on all cooking zones which are “hot”. All
other cooking zone displays are not illuminated.
