16

5.

  After  that,  detach  control  switches  of  the  cooktop.  Make  setting  by

turning the screw in the middle of gas cocks with a small screwdriver in
the manner shown in the following picture. To adjust flow rate screw, use
a screwdriver having suitable dimension. For LPG, turn the screw clockwise.
For natural gas, turn the screw one time counter clockwise.  At low
position, length of normal flame should be 6-7 mm. For the last control,
check out whether flame is open or closed.

Setting of your appliance may differ according to the type of gas cock used.

Ventilation Of Room

The air needed for burning is received from room air and the gases emitted

are given directly in room. For safe operation of your product, good room
ventilation is a precondition. If no window or room to be utilized for room
ventilation is available, additional ventilation should be installed. However,
room has a door opening outside, it is no needed to vent holes.

Room size

Ventilating opening

Smaller than 5 m³

min. 100 cm²

Between 5 m³ - 10 m³

min. 50 cm²

Bigger than 10 m³

no need

In basement or cellar

min. 65 cm²

Figure 4

Figure 5

GB
