English

TEchnical passporT

gas hob

stated  under  the  product  fit  those  of

your home. Call the authorized service

dealer for possible gas type changes in

future.

Â

When the unit was taken off its

packaging make sure that it is strong,

not bent and has no fault at all. In the

event of any doubt consult the dealer.

Â

Cut off the electric connection of

the unit from the main switch during

installation.

Â

In order that built in cook-

tops will operate smoothly the

measurements of the counter on which

it will be mounted and the materials

used for installation should be proper,

and the counter should be resistant

against heat.

Read the following instructions

to fix the hob on the counter:

In order to prevent insertion of the

foreign materials and liquids between

the hob and the counter attache the

adhesive band on the counter hole

without allowing any overlapping

before the installation.

Place the hob on the counter hole to

center the installation hole.

Secure the unit on the counter by

using the installation sheet and screws.

Please  review  the  following  figures

carefully so that the hob will be

installed properly.

6.2. INSTALLING THE

APPLIANCE

Check that the appliance is in a good

condition after having removed the

outer packaging and internal wrappings

from around the various loose parts.

In case of doubt, do not use the

appliance  and  contact  qualified

personnel.

Never leave the packaging materials

(cardboard, bags, polystyrene foam,
nails, etc.) within children’s reach since
they could become potential sources of
danger.

The measurements of the opening

made in the top of the modular cabinet
and into which the hot plate will be

installed are indicated in either ( fig. 9. )

Always comply with the

measurements given for the hole into
which the appliance will be recessed.

The hot plate has a special seal

which  prevents  liquid  from  infiltrating

into the cabinet.Strictly comply with
the following instructions in order to
correctly apply this seal:

Â

Take off all the movable parts of

the hob.

Â

Cut the seal in 4 parts of the

necessary lenght to positionning it on
the 4 edges of the crystal.

Â

Overturn the hot plate and

correctly position seal «E» (fig. 11) under

the edge of the hob itself, so that the
outer side of the seal perfectly matches
the outer perimetral edge of the hob.

The ends of the strips must fit together

without overlapping.

Â

Evenly  and  securely  fix  the  seal

to the hob

Â

Fit the hot plate into the hole in

the cabinet and lock it in place with the

relative screws of the fixing hooks (see
fig 12 )
