USER MANUAL
ENGLISH
ENGLISH
USER MANUAL
Table top cooker & built - in cooker
Table top cooker & built - in cooker
S E CT I O N 3.
T H I N G S TO B E CO N S I D E R E D P R I O R TO U S E O F T H E TA B L E TO P
CO O K E R A N D S A F E TY WA R N I N G S
Position the product so as to reach to the
power cord. Supply voltage of your product
is 220Y. The earth plug on the power cord
should be definitely used with an earthed
power socket.
Â
Our products are fueled by liquefied
petroleum gas or natural gas depending
on its version (optional).
Â
Apply to the authorized service center
to switch your product to liquefied
petroleum gas or Natural Gas.
Â
Have the mains connection and earthing
installation by a qualified electrician.
Â
Our firm may not be held responsible for
any damages that may arise from failure
to comply with the instructions given
above.
Â
When you use your cookers with
liquefied petroleum gas, use pressure-
reducing valve TSE 300 mm SS with
outlet pressure of 1.5 kg/h.
Connect your product to liquefied
petroleum gas cylinder by the short plastic
hose in a gas-proof manner.
Connect your product to the Natural Gas
cock by the spiral hose in a gas-roof manner.
The hose to be used should not be
longer than 125cm for safety purpose.
When placing your product, take care
that the gas hose or power cord does not
remain under the body. Do not run it near the
burners, otherwise cable insulation may he
damaged.
When the power cord is damaged,
replace it by visiting the nearest
authorized service center.
When gas connection is completed, do
not move your product beyond the limits that
the gas hose allows. Any forcing may cause
gas leakage from the hose connections.
Do not operate it without putting
pan, etc. on the electric cooker.
The stainless steel around the electric
cooker may change color due to heat. It is not
problem for use of it.
In order to make your product ready for
use, you should first prepare the installation
place and complete the electric installation.
And then call our authorized service
personnel.
Note: Start use after removal of the
protective film on Inox surface.
I N S TA L L AT I O N O F T H E B U I LT
-I N CO O K E R 400 S E R I E S
Figure 3
Figure 4
Worktop cutting measure is given in Figure 7 for placing the cooker. Into the worktop cut
to these measures, place the cooker of which the initial preparations were performed.
If you will use the cooker on the built-in oven, then comply with the Figures 8 and 9 for
proper clearance between the oven and cooker to allow air circulation.
Figure 1
Figure 2
UPPER TRAY
SILICONE SEAL
WORKTOP SURFACE
CONNECTION CLIP
SCREW
Please place the silicone seal along the edges of the cooker (Figure 1). Finally, you. should
fix it on the lower edges of the work surface by means of clamps and screws (Figure 2).
