www.timberk.com • electric humidifier

7

8. CLEANING AND MAINTENANCE

Before cleaning the device make sure that the plug is disconnected from

the wall outlet. Otherwise, it may result in electric shock.

Before cleaning, wait until the cooling water in the ground, so as not to

burn your hands. Spend device cleaning once or twice a week.
To clean the outer surface of the unit with a damp soft cloth.

To avoid electric shock, do not scratch or damage the device while

cleaning elements.
Do not use when cleaning the device thinner, benzene, dimethyl benzene,

stiff brush, talcum powder and other materials, except water.

Wipe any remaining water inside the base with a damp, soft cloth.

To remove the remaining water in the small details, you can use a soft

brush, then wipe it again with a soft cloth.

In the formation of dirt on the membrane, clean it with a soft brushes. Use

a soft brush to erase the remnants of water on the surface of the device,

and then wipe it again with a soft cloth.
Rinse water tank and a clean water dispenser.

After removal of the residual water from the surface of the sprayer, wipe it

with a soft cloth. Clean the outside surface with a damp, soft cloth.

IMPORTANT!

To avoid deformation or wear of working surfaces,

resulting in decreased atomizing or other malfunctions,

do not use metallic brushes, blades or talc powder

to wipe the atomizer’s surface. The water tank may

leak upon heavy impacts. In case of water leakage,

immediately stop using the unit and contact a service

center. To keep the unit dry, remove water after cleaning

and make sure to dry the unit’s case. Make sure that

there is no water left inside the unit’s case. Prior to a

long break in using the unit, dry its surface and pack it

into a plastic bag, then put it into a box. Store the unit in

a low-humidity room. Storing the unit undried results in

generation of mold

In case of emergencies use troubleshooting methods, listed in Table 2.

If it is impossible to remedy problems by the listed methods, contact the

manufacturer’s service center.

9. TROUBLESHOOTING

Table 2

Problem

Possible cause

Remedy

Poor atomizing (insufficient
capacity)

The unit is operating in the minimized
mode (low atomizing frequency)

There is no problem. If you need to switch
to the intensive mode of operation, turn the
regulator handle all the way to the right.

The atomizer is clogged

Clean the atomizer.

Temperature of water in the tank is too low

Set maximum capacity. The humidifier’s
capacity will go up after a while.

No atomizing

The power cord is poorly connected
to the outlet

Connect the power cord into the outlet
carefully

There is white deposit on objects
around the humidifier (salts,
separating out from water)

1. Lime deposits have formed on the
membrane
2. There is a lot of salts in the water used
(calcium and magnesium)

1. Clean the humidifier’s membrane with a
special brush
2. Use filtered water

Steam has an unpleasant odor

Stale water is used

Clean the unit according to the cleaning
and servicing instructions and fill the tank
with fresh water

Remains of stale water or waste have
accumulated in the unit’s case or the
atomizer

Condensate is formed on the
upper part of the humidifier and
on surrounding objects, when it is
operating.

1. High humidification intensity is set.
2. High room humidity and temperature.

Lower the humidification intensity by
turning the on/off and steam outflow
intensity regulator counterclockwise.

Water appears next to the humidifier,
when it is operating.

1. High humidification intensity is set.
2. Lime deposits have formed on the
membrane and in grooves for water (in
the unit’s base).

1. Lower the humidification intensity by
turning the on/off and steam outflow
intensity regulator counterclockwise.
2. Clean the unit according to the cleaning
and servicing instructions.

Water appears next to the humidifier,
when it is not operating

Water tank is leaking

You need to contact an authorized service
center
