www.timberk.com •

electric humidifier

5

TIMER 1

2 4

8

HUMID

%RH

1. Power ON / OFF button

2. Timer button
3. LED light button
4. Mist intensity button: low, medium, high
5. Indicator of absence of water
6. Indication of the current humidity
7. Indication of steam output intensity
8. Timer indicators (TIMER): switch off the device after 1h, 2h, 4h, 8h

5. SCOPE OF DELIVERY

1. Air humidifier – 1 pc.

2. Instruction manual and warranty card - 1 pc.

3. Package – 1 pc.

4. Brush-1 pc.

Fig.2

6. FILLING THE TANK WITH WATER

7. OPERATION OF THE DEVICE

1. Remove the tank from the stand and remove the top cover from it.

2. Pour water in the reservoir no higher than the maximum water level

scale «MAX».

3. Install the top tank cover and install it on the stand.

4. Check that the tank on the stand is installed securely, then connect the

plug of the power cord to an electrical outlet.

Switching the device on

Set  the  device  strictly  vertically  on  a  flat,  dry  surface,  then  connect  the

device  to  the  electrical  network,  previously  filling  the  reservoir  with  water

the ON/OFF blue indicator on the dispaly will light up Press the «ON / OFF»

button, the device will automatically start to work, the button illumination

will light and the display of the steam output and the current humidity

value will appear on the display. The appliance will turn on, the operation

indicator  will  light  up  on  the  control  panel  and  steam  will  flow  from  the

sprayer. At the very beginning of this operation, the level of spraying can be

unstable, which is caused by the temperature difference and water quality.

It will take a short time for this process to stabilize.

Steam output intensity adjustment

To change the intensity of the steam output, press the «Mist intensity»

button several times, the intensity of the steam output will vary: high,

medium, low, and accordingly the intensity of the steam output will be

displayed  by  the  indicators  on  the  panel.  Comfortable  conditions  are

achieved with a relative humidity of 40 to 60%. You can determine the

favorable humidity level for you by your own sensations, or you can use

a special hygrometer (not supplied) for this purpose, which measures the

relative humidity level.
