www.timberk.com • ultrasonic humidifier

5

1. Top cover

2. Aroma box

3. Water Tank

4. Control button

5. Bottom part

6. Mist Nozzle

7. Mist generation

8. Power cord

5. SCOPE OF DELIVERY

1. Air humidifier – 1 pc.
2. Instruction manual and warranty card - 1 pc.
3. Package – 1 pc.

6. FILLING THE TANK WITH WATER

1. Remove the tank from the stand and remove the top cover

from it.

2. Pour water in the reservoir no higher than the maximum water

level scale «MAX».

3. Install the top tank cover and install it on the stand.

4. Check that the tank on the stand is installed securely, then

connect the plug of the power cord to an electrical outlet.

Fig. 2

7. OPERATION OF THE UNIT

Set the device strictly vertically on a flat, dry surface, then

connect the device to the electrical network, previously filling the

reservoir with water. Press the on / off button and select the

steam output intensity (Fig. 2). The device will turn on, the light

blue work indicator will light up on the control panel and steam

will flow from the sprayer. At the very beginning of this operation,

the level of spraying can be unstable, which is caused by the

temperature difference and water quality. It will take a short time

for this process to stabilize.

Steam output intensity adjustment

In order to change the intensity of the steam output, press the

button on the control panel several times, the intensity of the

steam output will change: off, high, low.

Comfortable conditions are achieved with a relative humidity

of 40 to 60%. You can determine the favorable humidity level

for you by your own sensations, or you can use a special

hygrometer (not supplied) for this purpose, which measures the

relative humidity level.

Automatic shutdown in the absence of water

If the water level in the tank drops below the minimum

permissible level, the ultrasonic membrane of the device will

automatically turn off, while the red indicator lights up on the

control panel. To continue the operation of the device it is

necessary to fill the reservoir with water according to item 6
