www.timberk.com • electric humidifier

7

In case of emergency, please, use the troubleshooting methods shown in

tables. If it is impossible to solve problems with these methods, apply to

the service center.

11. TROUBLESHOOTING

Table 2

Problem

Possible cause

Remedy

Poor atomizing (insufficient
capacity)

The unit is operating in the minimized
mode (low atomizing frequency)

There is no problem. If you need to switch
to the intensive mode of operation, turn the
regulator handle all the way to the right.

The atomizer is clogged

Clean the atomizer.

Temperature of water in the tank is too low

Set maximum capacity. The humidifier’s
capacity will go up after a while.

No atomizing

The power cord is poorly connected
to the outlet

Connect the power cord into the outlet
carefully

There is white deposit on objects
around the humidifier (salts,
separating out from water)

1. Lime deposits have formed on the
membrane
2. There is a lot of salts in the water used
(calcium and magnesium)

1. Clean the humidifier’s membrane with a
special brush
2. Use filtered water

Steam has an unpleasant odor

Stale water is used

Clean the unit according to the cleaning
and servicing instructions and fill the tank
with fresh water

Remains of stale water or waste have
accumulated in the unit’s case or the
atomizer

Condensate is formed on the
upper part of the humidifier and
on surrounding objects, when it is
operating.

1. High humidification intensity is set.
2. High room humidity and temperature.

Lower the humidification intensity by
turning the on/off and steam outflow
intensity regulator counterclockwise.

Water appears next to the humidifier,
when it is operating.

1. High humidification intensity is set.
2. Lime deposits have formed on the
membrane and in grooves for water (in
the unit’s base).

1. Lower the humidification intensity by
turning the on/off and steam outflow
intensity regulator counterclockwise.
2. Clean the unit according to the cleaning
and servicing instructions.

Water appears next to the humidifier,
when it is not operating

Water tank is leaking

You need to contact an authorized service
center

Service life of the humidifier is 2 years.
At the end of its service life the humidifier should be utilized in accordance

with regulations and procedures, which are in force at the place of utilization.

12. DISPOSAL

10. TRANSPORTATION AND STORAGE

1. When transporting, any possible impacts and movements of the

package inside a vehicle must be avoided.
2. Handling symbols on the unit’s package must be strictly observed when

transporting and storing it.
3.

Temperature

requirements*
Humidity

requirements*

Transportation and

storage

-30°C to +50°C

15% to 85%

(no condensate)

We are researching new technologies and constantly improving the quality

of our products. Specifications, design and scope of delivery may be

changed without any prior notice.

* Products must be stored in dry, ventilated storages at the temperature not lower than -30°C.

IMPORTANT!

To avoid deformation or wear of working surfaces,

resulting in decreased atomizing or other malfunctions,

do not use metallic brushes, blades or talc powder

to wipe the atomizer’s surface. The water tank may

leak upon heavy impacts. In case of water leakage,

immediately stop using the unit and contact a service

center. To keep the unit dry, remove water after cleaning

and make sure to dry the unit’s case. Make sure that

there is no water left inside the unit’s case. Prior to a long

break in using the unit, dry its surface and pack it into

a plastic bag, then put it into a box. Store the unit in a

low-humidity room. Storing the unit undried results in

generation of mold.

•

Switch off the appliance and unplug it from the socket before cleaning it.

•

Clean the water tank and the base regularly. Use water only, no

detergents.
Always unplug the unit before removing the water tank. Do not touch the

water in the base during operation!
