www.timberk.com • electric humidifier

5

1. Air humidifier – 1

2. Instruction manual and warranty card - 1

3. Package - 1

1. Remove the water tank from the base and unscrew the water tank cover.
2. Make sure no foreign objects are in the water tank.
3. Fill the tank with clean, cold water. Close the cover of the water tank

securely, place the water tank onto the base. The water will running from

the tank into the base.
4. Don’t pour water into the mist outlet of the appliance.

5. LIST OF PARTS

6. FILLING OF TANK WITH WATER

IMPORTANT!

To avoid electric shock, prior to disassembling the

unit (removing the tank), disconnect the unit from the

power line! Do not fill the tank with other liquids but

tap water. Different composition of liquids has harmful

effect on internal parts and causes failures. Do not

fill the unit or the water tank with such additives as

essential oils, fragrances, cleaning agents, chemical

medical drugs, warm water (above 40°), etc.

Otherwise, the water tank and internal parts of the

unit will be damaged and inoperable.
Do not fill water directly into the internal part of the

unit or the atomizer. Water inside the unit may cause

failure of the unit. Do not hit or throw the water tank.

It may get damaged resulting in water leaks. Do not

use the unit in case if the water tank is heavily hit.

Immediately contact the technical support service or

the maintenance and repair station. Every day fill the

tank with fresh water and keep the unit clean.

1

3

2

4

5

6

7

8

9

10

Control panel for THU UL 16E (W)/(BL)

1. On/Off button

2. Power indicator

3. Current temperature value (TEMP)

4. Switch off timer setting button

5. SLEEP mode indicator

6. No water indicator

7. SLEEP mode activation button

8. Steam outflow indicators

9. Steam outflow intensity selection button

10. Appliance operation mode indicator

7. APPLIANCE OPERATION

Operation of THU UL 16M model

Switching on

Install the appliance to a true vertical on an even and dry surface, then

connect it to the power line, having filled the tank with water first. Turn

the on/off and steam outflow intensity knob all the way to the right. The

appliance will switch on, the blue operation indicator will light up on the

control panel and steam will start coming from the atomizer. At the very

beginning of operation, the atomizing level may appear unstable, which is

caused by the temperature difference and water quality. It will take short

time for this process to stabilize.

Adjusting steam outflow intensity

You can adjust steam intensity by turning the on/off and steam outflow intensity

knob to the left or right.

5. Insert the plug into the socket and switch on the appliance using

the button. The red empty indicator light may stay illuminated for some

seconds until the base is filled with water. Then the blue light comes on.
