www.timberk.com • electric humidifier

6

Always unplug the unit before removing the water tank. Do not touch the

water in the base during operation!
Caution-risk of electric shock and damage of the product!

8. CLEANING AND MAINTENANCE

Comfortable conditions are reached at 40 to 60% relative air humidity. You can

determine the humidity level favorable for you either according to your feelings

or by using a special device called a hygrometer (not included in the scope of

supply), measuring the relative humidity level.

Automatic switching off when there is no water

When water level in the tank drops below the minimum allowed one, the

appliance’s ultrasonic membrane will automatically switch off and a red indicator

will light up on the control panel. To continue operation of the appliance it is

necessary to fill the tank with water according to item 6 «Filling of tank with

water», and then connect the appliance to the electric mains.

Switching off

To switch the appliance off, turn the on/off and steam outflow intensity knob all

the way to the left and disconnect the appliance from the electric mains.

Operation of THU UL 16E model

Switching on

Install the appliance to a true vertical on an even and dry surface, then

connect it to the power line, having filled the tank with water first. Press

button «     » on the control panel, the appliance will automatically start

operating, and the operation mode indicator, steam outflow indicators and

the current temperature value will light up on the display.
At the very beginning of operation, the atomizing level may appear

unstable, which is caused by the temperature difference and water quality.

It will take some time for water to transform into steam in the ultrasonic

membrane and for this process to stabilize. In 10-25 minutes of operation,

the atomizing level will gradually stabilize.

Adjusting steam outflow intensity

To select the operation mode and adjust the steam outflow intensity, press

button «     » on the control panel several times, the steam outflow intensity

will be changing: low, moderate, high, and the steam outflow intensity will

be shown by the operation mode indicator on the display: 0,1,2,3.
Comfortable conditions are reached at 40 to 60% relative air humidity. You

ATTENTION!

If a large amount of condensate is generated on the upper

part of the appliance when it is operating, then you need to

decrease the steam outflow intensity by turning the on/off

and steam outflow intensity knob counterclockwise.

Switch off timer

To set the switch off timer, press button «     » on the control panel several

times, upon that the set time value of the timer until switching off will be

shown on the display (from 1 to 12).

SLEEP mode

The display brightness is automatically reduced in this mode.
To activate the SLEEP mode, press button «     » on the control panel, upon

that the SLEEP mode indicator will be shown on the display. To deactivate

this mode, press button «     » on the control panel again, upon that the

SLEEP mode indicator on the display will go off.

Automatic switching off when there is no water

When water level in the tank drops below the minimum allowed one, the

appliance’s ultrasonic membrane will automatically switch off and the no water

indicator «     » will light up on the control panel. To continue operation of the

appliance it is necessary to fill the tank with water according to item 6 «Filling of

tank with water», and then connect the appliance to the electric mains.

Switching off

To switch the appliance off, press button «     » on the control panel and

disconnect the appliance from the electric mains.

ATTENTION!

If a large amount of condensate is generated on the

upper part of the appliance and around it when it is

operating, then you need to decrease the steam outflow

intensity by pressing button «     » on the control panel

and by selecting a less powerful operation mode.

can determine the humidity level favorable for you either according to your

feelings or by using a special device called a hygrometer (not included in

the scope of supply), measuring the relative humidity level.
