Prior to cleaning the unit make sure the power supply’s plug is disconnected

from the outlet. Otherwise, it may cause electric shock.
Prior to cleaning wait until water, remaining in the unit’s case, completely

8. CLEANING AND MAINTENANCE

IMPORTANT!

To avoid electric shock, prior to disassembling the

unit (removing the tank), disconnect the unit from the

power line! Do not fill the tank with other liquids but

tap water.
Different composition of liquids has harmful effect on

internal parts and causes failures.
Do not fill the unit or the water tank with such

additives as essential oils, fragrances, cleaning

agents, chemical medical drugs, warm water (above

40°), etc.
Otherwise, the water tank and internal parts of the

unit will be damaged and inoperable.
Do not fill water directly into the internal part of the

unit or the atomizer.
Water inside the unit may cause failure of the unit.
Do not hit or throw the water tank. It may get damaged

resulting in water leaks. Do not use the unit in case if

the water tank is heavily hit.
Immediately contact the technical support service or

the maintenance and repair station.
Every day fill the tank with fresh water and keep the

unit clean.

7. OPERATION OF THE UNIT

Install the unit to a true vertical on an even and dry surface, then connect

it to the power line, having filled the tank with water first, at the same time

the «      » indicator will be blinking on the LCD display.
Press the «      » button and the unit will automatically start operating, and

indicators will show up on the LCD display.
At the very beginning of operation, the atomizing level may appear

unstable, which is caused by the temperature difference and water quality.

It takes some time for water to start turning into steam on the ultrasonic

membrane. After 10-25 minutes the atomizing level will gradually stabilize.
To select the operation mode and change the steam outflow intensity press

the «      » button several times, the steam outflow intensity will be changed

each time and shown on the display by indicators.
The display shows the current humidity level and temperature.
The unit will be turned off if water is completely used up, at the same time

the no water indicator «      » will light up.
To continue operation of the unit, add water in accordance with the

instructions (section 6 Filling the tank with water).
In the automatic operation mode (A indicator) the steam outflow intensity

will be adjusted automatically.
If the relative humidity level is less than 40% then the humidifier will operate

in the 6th steam outflow intensity mode.
If the relative humidity level is 40% to 50% then the humidifier will operate

in the 4th steam outflow intensity mode.
If the relative humidity level is 50% to 60% then the humidifier will operate

in the 3rd steam outflow intensity mode.
If the relative humidity level is over 60% then the humidifier will operate in

the 1st steam outflow intensity mode.
The unit is equipped with a compartment for aromatic oil. If aromatic oil is

added to this compartment then there will be air aromatization. Aromatic

oil is not included in the scope of delivery. To remove the compartment for

aromatic oil press button 7 (see Fig. 1).
To turn off the unit press the «      » button.

NOTE:

When using the humidifier, you may come across

condensate generation on its upper part and objects

next to it, including water accumulation, which is not

a defect, but a feature of its operation. This feature

may have several causes, listed in table 2 on page 7.
