5

ENGLISH

In automatic mode (the LED Auto) performance on humidifying device is

automatically adjusted.

If the humidity is 50-60% and above, includes economical mode

Econom.

If the humidity level of 40-50%, included a comfortable mode of

Comfort.

If the humidity is 40% or less, included intensive mode Turbo.
Indication of level of relative humidity

In the process of the device in the display area is displayed through the

plastic of the current level of relative humidity in the room (figure).

The optimum relative humidity for a man of 40-60%.
In addition, the device is equipped with a color indicator of moisture.

The vertical luminescent band in the center of the device changes color

depending on the level of relative humidity.

White LED indicates that the air is dry enough (40% and below).

Blue indicator light shows that air in the room good, moist (40-60%).

Green light indicates that the air is excessively humid (60% and above).

Blocking panel

To protect user-selected settings control panel can be locked. To do this

within 3 seconds to hold the lock button 8.

8. Cleaning and maintenance of the unit

Prior  to  cleaning  make  sure  that  the  plug  is  disconnected  from  an  outlet.

Otherwise it may result in an electric shock.

Before  cleaning,  wait  until  water  in  grooves  is  completely  cooled  down  in

order not to burn hands.

8.1 To wipe the external surface of the unit use a damp and soft cloth.

To  prevent  an  electric  shock  do  not  scratch  and  do  not  damage  unit s

elements upon cleaning.

When cleaning the unit, do not use solvents, benzine, dimethylbenzene, hard

brush, talc powder and other substances other than water.

8.2 Wipe water remains inside the groove under the tank by a damp and soft

cloth.k.

9. Troubleshooting

In case of emergencies resort to troubleshooting methods, given in tables.

If you are unable to solve issues by means of mentioned methods, contact

a service center.Life of the humidifier is 5 years.

Upon expiration of the humidifier it must be disposed in accordance with

regulations, rules and by means, currently in force at a disposal station.

To remove water remains on small parts you can use the brush, and then wipe

them again with a soft cloth. Clean the unit once or twice a wee

7. Operation of the unit

To disconnect the unit again, press Power (On/Off ).
The choice of operating modes

To select one of four modes of operation, press the 6 button (selection

mode). Above the button will illuminate the appropriate indicator.
In eco-mode operation (indicator Econom) performance on humidifying

device will be 180 ml/h (fan speed 1100 RPM, power 32 W). In this mode,

the tank will be spent over 22 hours. The noise level will not exceed 30

dB (A).
In comfort mode (indicator Comfort) on the instrument performance

hydration of 320 ml/h (fan speed 1100 RPM, power consumption 200

watts). In this mode, the tank is used up in 12 hours. The noise level will

not exceed 30 dB (A). In this mode, for better performance on

humidifying device uses hot

air

.

In intensive mode (LED Turbo) performance on humidifying device is

500 ml/h (fan speed 1600 rpm, power 380 W). In this mode, the tank will

be spent over 8 hours. The noise level will not exceed 40 dB (A). In this

mode, for better performance on humidifying device uses hot

air

.

Timer to shut down

By clicking on the timer, you can choose the time after which the device

will automatically shut off:

"     " - Shut off after 2 hours,

"     " - Off after 4 hours

"     " - Off in 6 hours

"     " - Shut off after 8 hours

.

www.timberk.com

electric air washer (purifier)
