8

-  clean ventilation slots J

2

 regularly with a brush or

compressed air

•  Regularly check the condition of the cutting head and the

tightness of nuts, bolts and screws

•  Regularly check for worn or damaged components and

have them repaired/replaced when necessary

•  Storage

&

-  store the tool

indoors

 in a dry and locked-up place,

out of reach of children

-  securely mount storage rail K on the wall with 4 screws

(

not supplied

) and horizontally leveled

•  If the tool should fail despite the care taken in

manufacturing and testing procedures, repair should be

carried out by an after-sales service centre for SKIL

power tools
-  send the tool

undismantled

 together with proof of

purchase to your dealer or the nearest SKIL service

station (addresses as well as the service diagram of

the tool are listed on www.skil.com)

TROUBlESHOOTING

•  The following listing shows problem symptoms, possible

causes and corrective actions (if these do not identify

and correct the problem, contact your dealer or service

station)

!  switch off the tool and disconnect the plug before

investigating the problem

★

Tool does not operate

-  power supply socket faulty -> use another socket

-  extension cord damaged -> replace extension cord

★ Tool operates intermittently

-  internal wiring defective -> contact dealer/service

station

-  on/of switch defective -> contact dealer/service

station

★ Tool vibrates abnormally

-  grass too high -> cut in stages

★

Tool does not cut

-  line too short/broken of -> feed the line manually

★ Line cannot be fed

-  spool empty -> replace spool

-  line entangled inside spool -> inspect spool; rewind if

necessary

★ Line is not cut of to correct length -> remove cover from

cutting blade

★

Line keeps breaking

-  line entangled inside spool -> inspect spool; rewind if

necessary

-  trimmer incorrectly used -> only trim with the tip of the

line; avoid stones, walls and other hard objects; feed

the line regularly

ENVIRONmENT

•

Do not dispose of electric tools, accessories and

packaging together with household waste material

(only for EU countries)

-  in observance of European Directive 2012/19/EC on

waste of electric and electronic equipment and its

implementation in accordance with national law,

electric tools that have reached the end of their life

must be collected separately and returned to an

environmentally compatible recycling facility

-  symbol

9

 will remind you of this when the need for

disposing occurs

DEClARATION OF CONFORmITY

•  We declare under our sole responsibility that the product

described under “Technical data” is in conformity with the

following standards or standardization documents: EN

60335, EN 61000, EN 55014 in accordance with the

provisions of the directives 2006/95/EC, 2004/108/EC,

2006/42/EC, 2000/14/EC, 2011/65/EU

•

Technical file at

: SKIL Europe BV (PT-SEU/ENG1),

4825 BD Breda, NL

¹ÊÁÂÆιƼ½ÊÇǾ¼½Æ

ȽʹÌÁÇÆËŵÆ¿Áƽ½ÊÁÆ¿

ÍÊÇȽƓˁ˅ʿ˂ ʽ¼¹Ɠ

Ĺ¾ ÁÂÿʹ¹¾

ÈÈÊÇιĹƹ¿½Ê

19.12.2013

10

NOISE/VIBRATION

•  Measured in accordance with EN 60335 the sound

pressure level of this tool is 70 dB(A) and the sound

power level 90 dB(A) (standard deviation: 3 dB), and the

vibration <2.5m/s² (hand-arm method; uncertainty K =

1.5 m/s²)

•  Measured in accordance with 2000/14/EC (EN/ISO

3744) the guaranteed sound power level LWA is lower

than 93 dB(A) (conformity assessment procedure

according to Annex VI)

Notiied body : KEMA, Arnhem, NL

Notiied body identiication number : 0344

•  The vibration emission level has been measured in

accordance with a standardised test given in EN 60335; it

may be used to compare one tool with another and as a

preliminary assessment of exposure to vibration when

using the tool for the applications mentioned

-  using the tool for diferent applications, or with diferent

or poorly maintained accessories, may signiicantly

increase

 the exposure level

-  the times when the tool is switched of or when it is

running but not actually doing the job, may signiicantly

reduce

 the exposure level

!  protect yourself against the effects of vibration

by maintaining the tool and its accessories,

keeping your hands warm, and organizing your

work patterns

Coupe-bordures

0735

INTRODUCTION

•  Cet outil est destiné à couper les herbes et mauvaises

herbes sous les buissons ainsi que sur les pentes et les
bordures qui ne peuvent être atteintes avec une tondeuse

•  Cet outil n’est conçu pour un usage professionnel
