8

3. SPECIFICATIONS

4. ASSEMBLY INSTRUCTION

The trimmer is supplied with some components not
assembled. To assemble these, proceed as follows:

4-1 Safety guard assembly

Fix the safety guard onto the motor housing.

(Fig. 2 & 3)

1. Put the safety guard onto the motor housing.
2. Rotate the safety guard to the right position.
3. Fix the safety guard on the motor housing with a

screw.

WARNING:

 Take care against injury from the

blade fitted to the guard for trimming the line to length.
After extending new line, always return the trimmer to its
normal operating position before switching on.

WARNING:

 Never fit metal cutting elements.

WARNING:

 Never use it without the safety guard

properly installed. Failure to adhere to this warning can
cause serious personal injury.

4-2 Auxiliary handle assembly

1. Attach the auxiliary handle to the support.

(Fig. 4)

2. Insert the bolt to the holes of the handle support and

the handle, and screw the lock knob to the bolt, but
don’t screw fully.

(Fig. 5)

3. Put the head of the machine on the ground, then

adjust the auxiliary handle to the comfortable position
by another handle for you:

(Fig. 6)

3a. Push the adjust button, adjust the tube length for

you want.

3b. Rotate the auxiliary handle on a comfortable angle

for you want.

4. Screw the lock knob to firm the auxiliary handle.

5. STARTING

Before start the trimmer, fix the extension cord into the
hole of the main handle.

(Fig. 7 & 8)

Take a secure hold the trimmer and without letting it touch
the grass to be cut, depress the safety lock button and the
switch trigger on the upper and grip.
To switch off the trimmer, release the switch trigger.

(Fig. 9)

WARNING:

 Switch on motor only when your

hands and feet are away from the cutting means.

6. UTILIZATION THE TRIMMER

AS AN EDGER

For edging of driveways and paths, transform the trimmer
from the trimmer mode to the edging mode as follows:
1. Hold the tube of the trimmer with one hand and push

the rotation button by another hand.

(Fig. 10)

2. Rotate the tube 180º until it locks in the edging mode.

(Fig. 11)

WARNING:

 To prevent accidental starting which

may cause serious personal injury, always disconnect the
power cord before attempting to rotate the shaft.

7. REPLACEMENT OF THE

CUTTING LINE CARTRIDGE

Your trimmer is supplied with a fully disposable cutting
line cartridge which overcomes troublesome rewinding of
the cutting line.
To replace an empty cutting line cartridge as follows:
1. Press both of the release latch on the spool holder

and boost up it out of the cap

(Fig. 12)

, remove the

empty spool out.

(Fig. 13)

2. Put the spring and cap out of the empty spool and into

the new spool, then feed the two cutting lines of the
new spool through the eyelets of the cap.

(Fig. 14)

3. Put the new spool into the spool holder, and then

press the cap down till lock into place by the release
latch.

(Fig. 15)

Model

UR3000

Rated voltage:

230 - 240 V~

Rated frequency:

50 - 60 Hz

Rated power:

450 W

No load speed:

9,000 min

-1

Cutting width:

300 mm

Line size:

Φ

1.65 mm

Sound pressure level at operator’s position:

75.1 dB (A)  K=3 dB (A)

Guaranteed sound power level:

96 dB (A)

Vibration:

2.73 m/s

2

  K=1.5 m/s

2

Size (L/ W/ H):

1,016 - 1,256 / 301 / 262 mm

Net weight:

2.6 kg
