14 ENGLISH

Installing the protector

CAUTION:

While installing the protector, be

careful not to contact the nylon cord cutter on

the protector.

 Contact with the cutter could result in

personal injury.

►

Fig.17:

1.

 Screw

2.

 Protector

Mount the protector by fitting it on to the motor housing,

and then secure it with two screws.

Installing nylon cutting head

Optional accessory

CAUTION:

If the nylon cutting head acciden-

tally impacts a rock or hard object during oper

-

ation, stop the tool and inspect for any damage.

If the nylon cutting head is damaged, replace it

immediately.

 Use of a damaged cutting tool could

result in serious personal injury.

CAUTION:

Be sure to remove the hex wrench

after installation.

CAUTION:

When installing or removing the

nylon cutting head, be careful not to contact the

nylon cord cutter on the protector.

 Contact with the

cutter may result in personal injury.

NOTICE:

Be sure to use genuine Makita nylon

cutting head.

1.

Turn the tool upside down so that you can replace

the cutting tool easily.

2.

  Insert the hex wrench through the hole on the motor

housing and rotate the spindle until the spindle is locked.

►

Fig.18:

1.

 Hex wrench

2.

 Hole

3.

 Spindle

3.

Place the nylon cutting head onto the spindle and

tighten it by turning it clockwise.

►

Fig.19:

1.

 Nylon cutting head

4.

Remove the hex wrench.

To remove the nylon cutting head, turn it counterclock-

wise while locking the spindle with the hex wrench.

Attaching the shoulder harness

►

Fig.20:

1.

 Hook

Attach the hooks of the shoulder harness to the tool as

shown in the figure.

CAUTION:

Be sure to attach the hooks of the

shoulder harness to the tool securely. If the hooks

are attached incompletely, they may come off and

cause injury.

Hex wrench storage

CAUTION:

Be careful not to leave the hex

wrench inserted in the tool head.

It may cause

injury and/or damage to the tool.

When not in use, store the hex wrench as shown in the

figure to keep it from being lost.

►

Fig.21:

1.

 Hex wrench

OPERATION

Cutting the grass

Hold the grass trimmer at the angle of about 50° to the

ground. Move the grass trimmer from right to left slowly.

Cut the grass a few times from the top of the grass at

the tip of the nylon cord.

NOTICE:

Do not cut high grass at a time.

 Cutting

the high grass at a time near the root may cause the

nylon cutting head to be entangled by grass. This

may cause the motor overload, resulting in damage to

the grass trimmer.

NOTICE:

Use the grass trimmer without getting

the spool into a contact with the ground surface.

Using the spool contacting the ground surface may

cause the motor under overload resulting in damage

to the grass trimmer.

►

Fig.22

NOTICE:

Do not force the trimmer in densely

growing grass.

►

Fig.23

NOTICE:

Do not use the trimmer as if you dig out

the ground.

►

Fig.24

Cutting the grass near tree, block,

brick, or stone

Hold and tilt the grass trimmer at a height where the

spool does not touch the ground. Cut the grass using

the nylon cord tip like knocking the ground.

►

Fig.25

NOTICE:

When cutting the grass, move the grass

trimmer around the tree or blocks so that the

nylon cord does not touch the tree or blocks.

 It is

recommended to keep the tool more than 5 cm away

from the tree or block. If the nylon cord touch the tree

or block, the nylon cord may be torn. If the nylon cord

is torn in the spool, set the nylon cord again referring

to the replacement procedure in this manual.

Using the grass trimmer as an edger

Using the grass trimmer as an edger is suitable for

cutting the grass growing along the bricks or blocks.
Pull down the wire guard and rotate the grass trimmer

180°.

As shown in the figure, while contacting the wire guard

with the ground, move the grass trimmer to cut the

grass. You can cut the grass efficiently by walking in

parallel along the bricks or blocks.

►

Fig.26:

1.

 Wire guard
