English |

27

Lawn trimming/

Cutting around trees and bushes

Edge cutting

– Sound power level

dB(A)

91

92

– Uncertainty K

dB

= 3

= 3

Vibration total values ah (triax vector sum) and uncertainty K determined according to

EN 50636-2-91

– Vibration emission value a

h

m/s

2

7

7

– Uncertainty K

m/s

2

= 1.5

= 1.5

The vibration level given in these instructions has been
measured in accordance with a standardised measuring pro-
cedure and may be used to compare power tools. It can also
be used for a preliminary estimation of exposure to vibra-
tion.
The stated vibration level applies to the main applications of
the power tool. However, if the power tool is used for differ-
ent applications, with different application tools or poorly
maintained, the vibration level may differ. This can signific-
antly increase the exposure to vibration over the total work-
ing period.
To estimate the exposure to vibration accurately, the times
when the tool is switched off or when it is running but not ac-
tually being used should also be taken into account. This can
significantly reduce the exposure to vibration over the total
working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping the hands warm,
and organising workflows correctly.

Mounting and Operation

Action

Figure

Page

Product features

A

473

Delivery scope

B

474

Mounting the protection guard

C

474

Adjusting the working height

D

475

Folding out the handle

E

476

Mounting the wheel

F

476

Battery charging and inserting

G

477

Switching On and Off

H

477

Recommended position for grass
cutting

I

478

Recommended position for edge
trimming

J

479

Recommended position for cutting
under bushes

K

480

Removing the line spool

L

481

Winding line on spool

M

482

Mounting the line spool

N

483

Maintenance, Cleaning and Stor-
age

O

483

Action

Figure

Page

Accessories

P

484

Assembly

u

Caution: Switch the garden tool off and remove the
battery before performing any maintenance.

Mounting the protection guard (see figure C)

Slide the protection guard

(5)

 onto the trimmer head until a

click can be heard. Affix the protection guard

(5)

 to the trim-

mer head with the screw. The screw is already fitted to the
bottom housing upon delivery.
Never use the trimmer without the protection guard

(5)

mounted. After mounting, the protection guard

(5)

 may not

be removed from the trimmer.

Adjusting the working height (see figure D)

Press button

(10)

 and adjust the trimmer to the desired

height. Release button

(10)

.

Always use the trimmer in a working position, never in the
storage position. The storage position is when the trimmer is
fully retracted. When adjusting the working position, make
sure that the mechanism for height adjustment is properly
locked. A click can be heard when the mechanism engages.

Folding out the handle (see figure E)

Press and release button

(7)

, fold out the handle

(3)

 to the

stop and then release button

(7)

. Make sure that the handle

(3)

 is properly locked. Do not put the pressure on the handle

(3)

 while adjusting it.

Mounting the wheel (see figure F)

Mount wheel

(6)

 to the trimmer head. Observe correct posi-

tion of the arrows on the trimmer head. Ensure that the hook
engages properly in the tab. Turn the wheel

(6)

 against the

trimmer head until the lever

(11)

 can be heard to engage

with a click.
To remove, pull lever

(11)

 until it disengages and remove the

wheel

(6)

 in opposite direction.

Switching on

u

Caution: Switch garden tool off and remove battery
from machine before adjusting or cleaning.
