Operation

13

13

Operation

(Common Interface) menu screen and service
by consulting your dealer.

• Please do not insert or pull out the CI card

when power on. During initialization of the CI
card, please don’t operate the TV.

• Do not insert or pull out the CI card

frequently so as to avoid any damages of the
TV and the CI card.

• If there is no picture and/or sound with the

CI+ CAM module inserted, please contact the
customer support of the service provider.

USB operation

Background information

• This unit supports playback of video files

with AVI, MKV, MPG, DAT, MP4, TS, VOB
extension, with video codecs WMV V9,
H263, MPEG-4, MPEGII, XVID and audio
codecs PCM, WAV, MP3, DD(AC3).

  The above list of extensions and codecs

is for information only and is not a guarantee
that all files having the above extensions and
codecs sohuld be read by this unit.

• USB file systems supported: FAT16,

FAT32. 2.0 USB version is supported, maximum
capacity is 500 GB. Max. load: DC5V, 500 mA.
For correct and satisfactory operation, licensed
USB devices of famous brands should be
used with this unit. Avoid using USB devices of
unknown brands. Playback of some file formats
cannot be supported.

According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.

Warning: usage of external USB drives

containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.

Operations of file playback

• Insert a USB into the USB jack. Select

USB source and press OK button. The screen
will show a USB playback window, in which
you can select Movie, Music, Photo and File
contents to play by pressing LEFT/RIGHT
cursor buttons and OK button.

• Press cursor buttons to select Return

option and press OK button on the RC if you
want to go back to the previous menu.

• In the content menu, press cursor buttons

to select folder, press OK button on the RC
to enter it, then press cursor buttons to select
the file you want to watch or to listen to. When
highlighting the file, the file information will
appear and picture will be previewed (not
available for music files). Press PLAY buttons
on the RC to play the selected file.

• While playback, press

OK

 button; the

bottom of the screen will show playback menu
in which you can select an operation by LEFT/
RIGHT cursor buttons on the RC or perform
this operation by pressing OK button on the
RC. Some of the operations are as follows:

Play or pause playback

All files

Select previous file

All files

Select next file

All files

Stop plabyack and return to
previous menu

All files

Select repat playback mode

All files

Play music in background
mode when photo or text
file is being browsed (you
should select music file first)

and
Text

Show file information

All files

Rotate image clockwise


Rotate image anti-clockwise
