Operation

13

13

Operation

USB operation

General information

• This unit supports playback of video files

with AVI, TS, MP4, MKV, MOV extension, with
video codecs H264, MPEG2/4 and audio
codecs AAC, DD(AC3).
         The above list of extensions and codecs
is for information only and is not a guarantee
that all files having the above extensions and
codecs should be read by this unit.

  USB file systems supported: FAT32.

2.0 USB version is supported. Maximum
capacity 1 TB. For correct and satisfactory
operation, licensed USB devices of well-
known brands should be used with this unit.
Avoid using USB devices of unknown brands.
Playback of photos and music of only JPEG
and MP3 format is supported. The output
capability of the USB port is 500 mA.

• Some AVI files cannot be played due to

their parameters and recording conditions.
Video files with AVI extension exceeding 2 GB
in size may be played partially.

  According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.

Warning:

 usage of external USB drives

containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.

Operations of file playback

• Insert a USB into the USB port. Select

USB source and press OK button. The screen
will show a USB playback window, in which
you can select Movie, Music, Photo and File
contents to play by pressing LEFT/RIGHT
cursor buttons and OK button.

• Press cursor buttons to select Return

option and press OK button on the RC if you
want to go back to the previous menu.

• In the content menu, press cursor buttons

to select folder, press OK button on the RC
to enter it, then press cursor buttons to select
the file you want to watch or to listen to. When
highlighting the file, the file information will
appear and picture will be previewed (not
available for music files). Press PLAY/PAUSE
button on the RC to play the selected file.

• While playback, press INFO button; the

bottom of the screen will show playback menu
in which you can select an operation by LEFT/
RIGHT cursor buttons on the RC or perform
this operation by pressing OK button on the
RC. Some of the operations are as follows:

Play or pause playback

All files

Select previous file

All files

Select next file

All files

Stop plabyack and return to
previous menu

All files

Select repat playback mode

All files

Play music in background
mode when photo or text
file is being browsed (you
should select music file first)

and
Text

Show playlist

All files

Show file information

All files

Rotate image clockwise


Rotate image anti-clockwise


.
