Operation

13

13

Operation

USB operation

General information

  USB file systems supported: FAT32. 2.0

USB version is supported. Maximum capacity
1 TB. For correct and satisfactory operation,
licensed USB devices of well-known brands
should be used with this unit. Avoid using USB
devices of unknown brands. Playback of

photos

 and music of only JPEG and MP3

format is supported. The output capability of
the USB port is

500 m

A.

• This unit supports playback of video files

with AVI, TS, MP4, MKV, MOV extension,
with video codecs H264/AVC, H263,
MPEG1/2/4 and audio codecs PCM,
MP3, AAC

.

  The above list of extensions and codecs

is for information only and is not a guarantee
that all files having the above extensions and
codecs should be read by this unit.

• Some AVI files cannot be played due to

their parameters and recording conditions.
Video files with AVI extension exceeding 2 GB
in size may be played partially.

  According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.

Warning:

 usage of external USB drives

containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.

File playback

Insert a USB into the USB jack. Press

SOURCE

 button, select Media option and

press OK button. The screen will show USB
playback menu

.

USB


Music

Movie

• Video file playback: Select

Movie

item

and press OK button. Press cursor buttons
to select a file and press OK button to start
playback. During playback press MENU but-
ton to show playback menu in which you can
select an operation by LEFT/RIGHT cursor
buttons and perform this operation by press-
ing OK button. The operations include

Play/

Pause,FB,FF,Prev.,Next,Stop,Charset,Repeat

Mode,AB Repeat setting,Playlist,Info.,Slow

Forward,Step Forward, Goto Time,Zoom

In,Zoom Out,Aspect Ratio,Move View

. To exit

video playback press EXIT button.

•


 file playback: Select


item

and press OK button. Press cursor buttons
to select a file and press OK button to start
playback. During playback press MENU button
to show playback menu in which you can select
an operation by LEFT/RIGHT cursor buttons
and perform this operation by pressing OK
button. The operations include

:

Play/

Pause,Prev.,Next,Stop,RepeatMode

Music

，

Playlist

，

Info.,Rotate(Clockwise),Rotate

(Counterclockwise),Zoom In,Zoom Out,Move

View

. To exit photo playback press EXIT button.

•

Music

 file playback: Select

Music

item and

press OK button. Press cursor buttons to select
a file and press OK button to start playback.
During playback press MENU button to show
playback menu in which you can select an
operation by LEFT/RIGHT cursor buttons and
perform this operation by pressing OK button.
The operations include Play/Pause,

FB

,

FF

, Prev., Next, Stop, Repeat Mode, Mute,

Playlist, Info. and Goto Time. To exit music
playback press EXIT button.

CI Information

(only in DTV mode): This function enables

you to watch some encrypted services (pay
services). Please insert a CI card into the
