General Information

14

USB operation

Background information

•  This unit supports playback of video files

with 3GP, ASF, AVI, MKV, MPG, DAT, M2TS,
MP4, TS, VOB extension, with video codecs
WMV V9, DIVX, H263, MPEG-4, MPEGII, XVID
and audio codecs PCM, WAV, WMA, MP3,
DD(AC3).

  The above list of extensions and codecs

is for information only and is not a guarantee
that all files having the above extensions and
codecs sohuld be read by this unit.

•  USB file systems supported: NTFS, FAT16,

FAT32. 2.0 USB version is supported, maximum
capacity is 500 GB. Max. load: DC5V, 500 mA.
For correct and satisfactory operation, licensed
USB devices of famous brands should be
used with this unit. Avoid using USB devices of
unknown brands. Playback of some file formates
cannot be supported.

According to the USB 1.1/2.0 Standard,

usage of a USB device with power current
consumption exceeding 500 mA is not
recommended without supplementary power
supply. Failure to use supplementary power for
connected USB drives with power consumption
exceeding this value as well as defective
USB drives may cause mechanical or thermal
changes of elements of this unit as well as
failure of internal elements of the USB port.
Such damages are not warrantee cases.

Warning: usage of external USB drives

containing BIN files in the root directory may
cause malfunction of the unit or damage to the
software.

Operations of file playback

•  Insert a USB into the USB jack. Press the

DMP button or select USB source and press
ENTER button on the RC or VOL+/VOL- button
on the unit. The screen will show a USB
playback window, in which you can select
Music, Photo, Movie and Text contents to play
by pressing LEFT/RIGHT cursor buttons and

General Information

ENTER button.

•  Press cursor buttons to select Return

option and press ENTER button on the RC or
CH+/CH- button on the unit if you want to go
back to the previous menu.

•  In the content menu, press cursor buttons

to select folder, press ENTER button on the
RC or press and hold CH+/CH- button on the
unit to enter it, then press cursor buttons to
select the file you want to watch or to listen to.
When highlighting the file, the file information
will appear on the right and picture will be
previewed in the center (not available for music
files). Press   button on the RC or press and
hold CH+/CH- button on the unit to play the
selected file.

•  While playback, press INFO button; the

bottom of the screen will show playback menu
in which you can select an operation by LEFT/
RIGHT cursor buttons on the RC or perform
this operation by pressing ENTER button on
the RC.

•  While playback, press   button to pause

or resume playback. Press   button to stop
playback.

•  When you select a file to play, you can

delete the selected file by pressing Red button,
then ENTER on the RC.
•  When playing photo, movie and music files,
you can press REPEAT button to select the
repeat play mode.

•  When playing music files you can press

/

 buttons to fast reverse or forward. You can

press

/

 buttons to select the desired files

manually in normal condition.

•  When playing text files, you can press CH+/

CH- buttons to page up or page down the file.

•  Press EXIT button to stop playback and

return to the previous menu screen.
 corner, the list of the current available
channels on the left, and the name of each
programme starting in scheduled time periods
on the right. Select the channel by pressing
UP/DOWN and the programme by pressing
LEFT/RIGHT.
