Operation

7

7

Operation

Remote controller (RC)

1. POWER button
2. Number buttons
3. -/-- button
4. CH+/- buttons
5.

 button

6. SLEEP button
7. MENU button
8. Direction buttons (LEFT/RIGHT/UP/DOWN)
9. ENTER button
10. EXIT button
11. RED button
12. GREEN button
13. TEXT (

)/

 button

14. HOLD (

)/

 button

15. INDEX (

)/  button

16. SIZE (

)/  button

17. P.MODE button
18. S.MODE button
19. ASPECT button
20. STILL button
21. V+/- buttons
22. MTS button
23. SOURCE button
24. DISPLAY button
25. BLUE button
26. YELLOW button
27. SUBPAGE (

)/

 button

28. MIX/

 button

29. CANCEL (

) button

30. REVEAL (

) button

31. SWAP ( ) button

Changing the battery

1.  Remove the battery compartment cover

on the back of the RC.

2.  Insert the batteries into the battery

compartment making sure that the correct
polarity is observed.

3.  Install the cover back.

•  Use two AAA batteries for the RC. The RC

should be pointed at remote sensor within 8
meters and within 30 degrees at the left or the
right side.

•  Take the battery out of the RC if it is not

used for a long time.

•  Do not mix new and used batteries or

different types of batteries. Weak batteries can
leak and severely damage the RC.

•  Do not expose the RC to shock, liquids,

and do not place it in an area with high
humidity.

1

2

3

CH+

CH-
