Before you start

4

4

Before you start

Installation

Wall mounting

For wall mounting the back panel of this

unit is equipped with 4 screw holes (4 mm
diameter, 100 mm horizontal spread distance
x 100 mm vertical spread distance). A VESA
wall-mount bracket should be used for wall
mounting (the bracket is not included and
should be acquired separately). Manufacturer
is not responsible for improper mounting
resulting in damage of the unit.

Wall or ceiling mounting implements

must be durable and sufficient enough to
support the weight of the unit.

Stand installation

Place the LED TV on a solid flat surface.

Use soft material to place over the front screen
to avoid any damage. Then put the slits of the
stand onto the fixing elements in the lower part
of the unit until a click and fix the two parts by
three screws as shown below:

as well as the damage to the product.
•  Please place the product on a flat surface

in a well-ventilated location. Keep it away from
the burning-light, direct sunlight, vibration,
high-temperature and humidity.

•  Do not place any vase, potted plant, cup,

medicine and any container with water on this
product. If the liquid is spilt, it may cause the
fire, electric shock or breakdown.

•  Do not install it at the place on the strong

magnetic field or current field. It may cause
break down. This equipment may be observed
deterioration of the picture by electromagnetic
radiation in electromagnetic environment.

•  Fasten the wheel of the product or shelf

with wheels when installing this product. If it
moves or is tipped over, it may be damaged.

•  Do not place any fire source such as

candlelight close to this product or place it on
this product. If it is tipped over or fallen down, it
may cause damage or fire.

•  Do not place the unit into closed space

of TV for better ventilation; it can reduce the
product lifetime. Keep a space at least 10 cm
at above, left and right of the TV.

•  Please place all the signal cords behind of

rear panel.

•  Do not overexert or touch the panel when

you convey the product. Do not transfer the
LCD TV up or down display direction.

•  Do not transport it with the power cord

or the connection cable connected. If you
move this product with the power cord or the
connection cable connected, the damaged
power cord, connection cable or connection
terminal may cause the fire, the electric shock
or breakdown.

•  2 persons or more shall transport the

device, which is heavier than 18 kg. If you drop
or tip over the device, it can be damaged.

•  The temperature of the product’s body

becomes a little higher after a long period use.
This phenomenon indicates that heat exchange
in normal working mode, thus please do not
let children or anyone who is sensitive of
temperature to touch.

All images provided herein are schematic

drawings and may differ from of real objects.

M4x1 2
