10

1.

Following the directions printed on the CAM, gently

insert the module into the common interface slot on

the TV.

2.

Push the module in as far as it will go.

3.

Turn on the TV and wait for the common interface

function to be activated. This may take several

minutes.

Note:

 Do not remove the CAM from the slot. Removing

the module will deactivate the digital services.

Accessing Common Interface Services

After inserting and activating the CAM, press

on the

remote control, select

Channel

 >

Common Interface

and press

OK/

►

 to enter. This menu option is only

available if the CAM is correctly inserted and activated.

On-screen applications and content are provided by

your digital TV service operator.

Note

: This feature is only available under DTV source.

Using Subtitles

You can enable subtitles for each TV channel.

Subtitles are broadcast via Teletext or DVB-T/DVB-T2/

DVB-C/DVB-S/DVB-S2 digital broadcasts. With digital

broadcasts, you have the additional option of selecting a

preferred subtitle language.

Note:

 Some options are available only when

Subtitle

 is

set to on.

Turning On/Off Subtitles

1.

Press

on the remote control, select

Channel >

Subtitle

 and press

OK/►

 to enter.

2.

Select the

Subtitle

 option, and press

OK

 to toggle

between on or off.

3.

Press   to close the menu.

Enabling Subtitle Languages on Digital TV

Channels

1.

Press

on the remote control, select

Channel >

Subtitle > Digital subtitle language 1st

 and press

OK/►

 to enter.

2.

Press

▲

/

▼

 to select a subtitle language as your

preferred language and press

OK

 to confirm.

3.

Press

▲

/

▼

 to select

Digital subtitle language 2nd

and press

OK/►

 to enter.

4.

Press

▲

/

▼

 to select a secondary subtitle language

and press

OK

 to confirm.

5.

Press   to close the menu.

Installing Channels

This section describes how to search and store

channels automatically. This may be done in either of

the cases below:

-

you are prompted that there are no channels in TV

mode;

-

you want to update your channels.

1.

In TV mode, press

on the remote control and

select

Channel >

Channel scan

. Press

OK

/► to

enter.

2.

The TV installs and arranges channels according

to your country or region. Press ▲/▼ to select

Country/Region

, and press

OK

/► to enter. Enter

the default password 1234 or your own password in

case you have changed the password in the

System

>

Lock

menu. Press ▲/▼ to select your country or

region and press

OK

 to confirm.

3.

Press ▲/▼ to select

Automatic search

 and press

OK

/► to enter.

4.

Press ▲/▼ to select

Tuner mode

 and press ◄/► to

select

Cable

,

Antenna

 or

Satellite

.

(

Note

: Satellite

option is available only in selected models.)

5.

Press ▲/▼ to select other options and use ◄/► to

configure.

6.

After configuration is completed, press ▼ to select

Search

 and press

OK

 to start scanning channels.

7.

The channel search may take a few minutes. After

the automatic search, channels are arranged in a

preset order. If you wish to hide or swap channels,

press

on the remote control, select

Channel

 >

Channel organizer

 and press

OK

/► to enter.

Note:

If the channel search retrieved only the analogue

channels it could be caused by poor broadcasting

and therefore is not covered by manufacturer

warranty. Manufacturers cannot be held

responsible for lack of or poor broadcasting in

some areas.

Common Interface

(* not available for some models)

Encrypted digital TV channels can be decoded with a

Conditional Access Module (CAM) and a card provided

by a digital TV service operator.
The CAM may enable several digital services,

depending on the operator and services you choose

(for example, pay TV). Contact your digital TV service

operator for more information about services and terms.

Using the Common Interface Function

WARNING: Switch off your TV before inserting a

CAM. Be sure to follow the instructions described

below. Wrong insertion of a CAM may damage both

the module and your TV.

Chapter 4

Using More of Your TV
