Sharp LC-40FI3012E - Инструкция по эксплуатации - Страница 16

EN

Sound

Sound Mode

- Choose from the following presets

–

Standard

- Default settings

–

Music

- Emphasises music over voices

–

Movie

- Provides live and full sound for movies

–

Personal

- Selects your personal sound settings

–

Sports

- Emphasises sound for sports

TIP

: Treble and bass levels can only be adjusted when

the sound mode ‘Personal’ is selected.

Treble

- To adjust the level of high frequency within the sound.

Bass

- To adjust the level of low frequency within the sound.

Balance

- To switch the sound between the left and right speakers.

Auto Volume Level (AVL)

- When ‘on’ is selected, the volume

will stay at a constant level regardless of input/source.

DTS TruSurround

- Allows you to turn surround sound eff ect ON or OFF.

Digital Output

- This is the digital Audio output.

Choose from the following options:

–

Off

- Off

–

Auto

- Selects the best settings automatically

–

PCM

- Select this option if you are connecting to a Stereo

Hi-fi  via digital cable (Pulse-code modulation (PCM) is
a digital representation of an analogue signal)

SPDIF Delay (ms)

- Enables the user to adjust sound setting to sync picture

and audio for external speakers connected via digital audio output.

Audio Delay (ms)

- Enables the user to adjust sound

setting to sync picture and audio for TV speakers.

Audio Description

- Additional sound track for visually impaired.

Available only on selected DTV shows.

–

AD Volume

- to adjust volume of Audio Description sound track

Time

Clock

- Set the date and time. Date and time is

set up automatically in DVB mode.

Off  Time

- Allows you to set a specifi c time for your TV to turn off .

On Time

- Allows you to set a specifi c time for your TV to turn on, the

channel it will then display, the source it will be on and also the volume.
This function can then be toggled to repeat every day or a certain day.

Time Zone

- Change your current time zone.

Sleep Timer

- Lets you set the sleep timer so the television

automatically switches off  after a set amount of time.

Auto standby

- Adjustment for the auto standby in

hourly increments: Off  -> 3h -> 4h -> 5h.

OSD Timer

- Lets you adjust the amount of time the On

Screen Menu stays on the screen before disappearing.

Lock

System Lock

- Allows you to lock or unlock the menu. You will be

asked to enter a 4 digit password. Use the

◄

button to quit the

password input. Use the

►

 button to clear. Default password is 0000.

Set Password

- Change the default password.

Channel lock

- Lock specifi c TV channels.

Parental Guidance

- Lock TV channels based on age restriction.

Key Lock

- Lock the TV buttons.

 – Off

- All TV buttons are unlocked

 – Full

- All TV buttons are locked

Settings

Language

- Allows you to change the language of the menu.

Audio Languages

- Allows you to change audio

language on selected DVB channels.

Subtitle Language

- Allows you to change subtitles

language on selected DVB channels.

Hearing Impaired

- If signal provides support for the hearing

impaired, the subtitles can be played by pressing the “Subtitle”. If
you set Hearing Impaired ON and switch to a channel with supports
for hearing impaired subtitles will be activated automatically.

PVR File System

- PVR Recording options

–

Select Disk

- Select USB port and disk partition.

–

Check PVR File System

- Tests write speed and fi le

system of connected USB storage device.

–

USB Disk

- shows USB device status after the test.

–

Format

- you can format connected USB storage device to FAT32 fi le

system.

WARNING: ALL DATA ON THE USB DEVICE WILL BE DELETED

–

Timeshift Size

- information about size of timeshift buff er.

–

Speed

- information about speed of USB drive.

–

Free Record Limit

- set maximum duration of recordings.

Options are: 6Hr -> 5Hr -> 4Hr -> 3Hr -> 2Hr -> 1Hr.

LED Status

- Allows the user to switch the LED Power indicator light ON

or OFF, when the TV is being operated. ( When this option is set to OFF the
LED Power indicator light will flash when the remote control is used).

Blue Screen

- Changes the background when there is no input between

transparent and a blue background (Only available on some sources).

First Time Installation

- Starts the fi rst time installation.

Reset TV

- This resets the menus to factory settings.

Software Update (USB)

- From time to time we may release new

fi rmware to improve the operation of the television (available to
download). This menu lets you install the new software/fi rmware onto
the television. Further details of how to do this will be issued with the
fi rmware. Contact the helpline or refer to the ‘www.sharp.eu/av’ website.

WARNING

: Do not turn off  the TV’s power until the upgrade is complete!

HDMI CEC*

- Allows you to operate devices

connected via HDMI with TV remote control.

–

CEC Control

- set CEC functions on/off .

–

Audio Receiver

-  Sends audio signal from terrestrial/satellite

broadcast via HDMI to the AV receiver without using any additional
audio cables, this functions is available only on HDMI 1 output.

–

Device Auto Power Off

-  Automatically turn off   connected

devices via HDMI CEC, when you turn off  TV.

–

TV Auto Power On

- when you turn on any of connected

HDMI CEC devices, TV will start up automatically.

–

Device List

- show list of connected CEC devices

–

Device Menu

- Allows you to access devices menu and

operate the menu using TV remote control.

Version Info

- shows version of TV software

User manual

- user guide in electronic form.

Store Mode**

- switch ON/OFF shop demonstration mode

* - HDMI CEC must be supported by connected device.

** - available only if store mode was selected during fi rst time installa-
tion

7 Day TV Guide

TV Guide is available in Digital TV mode. It provides information about
forthcoming programmes (where supported by the Digital channel). You
can view the start and end time of all programmes and on all channels for
the next 7 days and set reminders.

1.

Press

[TV GUIDE]

. The following 7 Day TV Guide will appear.
