15

MENU

Displays Menu/OSD

SOURCE

Displays the input source menu

STANDBY

Standby Power On/Off

Choosing Mode Input/Source

To switch between the diff erent input/connections.

a) Using the buttons on the remote control:

1. Press

[SOURCE] - The source menu will appear.

2. Press

[

▲

] or [

▼

] to select the input you require.

3. Press

[OK].

b) Using the buttons on the Television:

1. Press

[SOURCE].

2.  Scroll up/down using CH+/CH- buttons to the input/source you

require.

3. Press

VOL+ to change input/source to the one selected.

Connections

Please see the exact connectors layout on the page 19.

USB

USB-Input 1, 2

HDMI 1, 2, 3 in

HDMI-Input 1, 2, 3

L

R

WR

R/L - Video  & YPbPr audio In

Component / Video audio input

Y

Video (CVBS)

VIDEO input

R

G

B

Component

/

YPbPr

Component HD Input

SCART

SCART-Input

CI Card IN

CI input

RF In

RF / TV Aerial Input

Sat In

Satellite Input

Digital Optical Audio Out

Digital optical output

HEADPHONES

3.5mm Headphone output

TV Menu navigation

To access this menu, press [MENU] button on the remote control. To enter
a menu press [OK]. If you wish to make changes to any of the default
settings, use the scroll (

▲/▼/◄/►)

buttons. To confi rm any settings press

[OK] button. To exit this menu at anytime, press [EXIT ] button.

Channel

Auto Tuning

- Allows you to retune the television for all digital

channels, digital radio stations and analogue channels.

Analogue Manual Tuning

- Allows you to

manually tune your analogue signal.

Digital Manual Tuning

- Allows you to manually tune your digital signal.

Channel Edit

- Allows you to delete, skip and add favourite channels.

–

Red Button

- delete selected channel.

–

Green Button

- rename selected channel.

–

Yellow Button

- Move selected channel. Go with cursor to

channel, which you wish to move to diff erent position, then
press YELLOW button. Now move selected channel with UP/
DOWN arrow to desired position and press YELLOW button
again to confi rm its new position in channel list.

–

Blue Button

- Skip selected channel. Channels selected to Skip

will not be displayed while pressing CH+ or CH- buttons.

Schedule List

- Lists your programme reminders.

Signal Information

- Information about DVB signal.

CI Information

- Pay per view services require a “smartcard” to be

inserted into the TV. If you subscribe to a pay per view service the
provider will issue you with a ‘CAM’ and a “smartcard”. The CAM can
then be inserted into the COMMON INTERFACE PORT (CI Card In).

Satellite Setup

- This menu is only available in DVB-S2 mode. You can

select the type of satellite, your transponder and your LNB type, etc.


Picture Mode

- Choose from the following presets.

–

Standard

- Default settings

–

Dynamic

- Recommended settings for fast moving pictures

–

Mild

- Set to be lighter in colour and less bright

–

Personal

- Lets you manually alter all the settings

–

Eco

- Consume 15% less energy.

Contrast

- Switch the balance between black and white.

Brightness

- Increase or decrease the brightness of the picture.

Colour

- Increases the colour from black and white.

Tint

- Lets you increase or decrease the level of tint

within the picture (for NTSC signal only)

Sharpness

- Increase or decrease the sharpness of the picture.

Colour Temperature

- Choose from the following presets.

–

Normal

- Default settings

–

Warm

- Increases red within the picture

–

Cold

- Increases blue within the picture

Noise Reduction

- Filters and reduces the

noise (interference) of the picture

Aspect Ratio

- Picture format varies depending on the channel/broadcast.

There are a number of diff erent options to best meet your needs.

–

Auto

- Automatically displays the best picture format.

So the picture is in the correct position. May have
black lines at the top/bottom and/or sides.

–

4:3

- Displays the 4:3 picture in its original size.

Side bars are shown to fi ll the 16:9 screen.

–

16:9

- Fills the screen with a regular 16:9 signal.

–

Zoom 1/2

- The picture is the correct proportion

but zoomed in to fi ll the screen.

–

Full

- Displays a picture in the full screen mode without overscan.

16:9 signal will be displayed in original proportion. Other
picture formats will be stretched to fi ll the screen. This option
is available only in Digital TV and Satellite input source.

–

Dot by Dot

- Will display the picture in its original resolution

without any change. Only available in HDMI input source.

HDMI Mode

- settings for HDMI sources.

–

Auto

- recommended option, TV will set best option

based on connected device by HDMI.

–

Video

- picture will be with overscan to get

optimal aspect ratio for watching movies.

–

VGA/PC

- picture will be without overscan. Set this option manually

in case part of screen is hidden, after you connect PC to the TV.
