EN

What is included in the box

Supply of this TV includes following parts:

•

1x TV

•

1x TV stand installation packet

•

1x Remote control

•

1x User guide

•

2x AAA batteries

Attaching the Stand

Please follow the instructions on last page of this user manual.

Wall mounting the TV

1.

Remove the four screws that are supplied in the wall mounting holes.

2.

The wall mount can now be easily attached to the mounting holes on
the rear of the TV.

3.

Install the wall mounting bracket to the television as advised by the

bracket manufacturer.

Getting started - initial set up

1.

Insert the batteries supplied into the Remote control.

2.

Using the RF cable, connect the TV to the TV Aerial wall socket.

3.

Connect the power cable to the Electrical outlet.

4.

Then press Standby button to power on TV.

5.

After turning on the TV you will see the menu "First Time
Installation". If the menu does not appear, You can recall it by
pressing the remote control buttons "Menu", then 8-8-8-8, so this
menu window would be re-opened.
If you wish to make changes to any of the default settings, use
the scroll ▲/▼/◄/► buttons. To exit this menu at anytime, press
[EXIT] button.

6.  Please set desired settings in FIRST TIME  INSTALLATION  screen.

DVB Antenna -

 You can choose between Terrestrial (DVB-T/T2), Cable

(DVB-C) or Satellite (DVB-S/S2).

Language -

 Set the TV Menu language.

Country -

 Set the desired country.

Tunning Mode -

 Choose if you want to tune only Digital (DTV )

Analogue (ATV ) or both Digital and Analogue (DTV + ATV )

Environment -

Select the location of TV.

For home use, please select Home Mode.
For shop demonstration mode, set Store Mode.

Sorting by LCN -

Set LCN to ON if you want to arrange channels by

provider preferences (only applies to DVB-T and DVB-C channels).

7.  Press [OK] button to start the tuning process.

8.  Optional channel presets DVB-C:

Keep all default settings as recommended.

If DVB-C channels are not found, contact your network provider for the
valid "Network ID". Then perform a new search. Press the [MENU], select
"Network ID" and enter the network ID.

9.  Optional channel presets DVB-S2:

 Select "Satellite" in the "DVB

Antenna" in the menu for the optional channel presets. Here you can
choose between the various satellites. Since selection completed, then
the channel list of the exact satellite will be available to be imported
into your TV system.

Confi rm with [OK] button on the remote control, to start scanning.

TIP:

If you are missing channels, the reason for this is likely to be signal

strength, you should consider connecting signal booster and re-tuning the TV.

Remote control

Refer to remote control picture on the second page of this user
manual.

1.

 STANDBY –

 Switch on TV when in standby or vice versa.

2.

 MUTE –

Mute the sound or vice versa.

3. DTV

–

 Switch to digital TV source.

4. RADIO

–

 Switch to Digital and switch between TV and radio in Digital

mode.

5. USB

–

Switch to USB source.

6. DVD

–

DVD

2

 – Switch to DVD mode

7.  0 – 9 –

to select a TV channel directly.

8.  TV GUIDE –

Opens the 7 Day TV Guide (Digital mode).

9.

 –

 To return to the previous channel viewed.

10. VOL

▲/▼

 –

 To increase / decrease the sound level.

11. S.MODE –

 Scrolls through sound mode options.

12. P.MODE –

 Scrolls through picture mode options.

13. FAV –

 To display favourites menu.

14. CH

 ▲/▼

 –

To increase or decrease the channel being watched.

15. (

▲/▼/◄/►

/ OK) –

Allows you to navigate the on-screen menus and

adjust the system settings to your preference.

16. MENU –

 To display OSD menu.

17. EXIT –

To exit all menus.

18. SOURCE –

To display the input/source menu.

19. INFO –

Press once for now/next channel information. Press twice for

programme information about current programme.

20. ASPECT –

To switch the screen between the diff erent picture formats.

21. SLEEP –

Press repeatedly to cycle through the sleep options.

22. AUDIO –

To change the audio language (if available).

23. SUBTITLE –

To switch the dialogue at the bottom of the screen (on/

off ).

24. TEXT –

Teletext mode - To enter Teletext

25.  TEXT HOLD –

Teletext mode - Hold current page which is displayed

26.  TEXT/ DVD ZOOM

2

 –

 DVD mode - Teletext Mode - To zoom in

27.

 DISPLAY –

 To switch off  the screen when listening to radio

28. Rec

1

/DVD MENU

2

–

 PVR Record / DVD mode - To display the DVD disc

menu

29. Rec List

1

/DVD SETUP

2

–

 Opens the list of recordings / DVD mode - To

display the DVD setup menu

30.

 –

 To restart the current chapter

31.

 –

 To advance forward to the next chapter

32.

 /

 –

 To stop the playback / To EJECT the disc press/hold the button

for 4 seconds.

33.

 –

 To play in fast rewind mode.

34.

 –

 To play in fast forward mode.

35.

 –

 To play/pause

36. COLOUR BUTTONS

–

 Additional teletext and OSD functions

GOTO

2

 – DVD mode

- To go to a specifi c chapter

A–B

2

 – DVD mode

- Press once to set point,

press a second time to return to point

ANGLE

2

 – DVD mode

- Select diff erent angle of DVD (if available)

REPEAT

2

 – DVD mode

- USB mode -To repeat playback

1

 - available only with PVR function

2

 - available only for TVs with DVD player

TV buttons & Source menu

Vol+

Volume up and menu right

Vol-

Volume down and menu left

CH+

Programme/Channel up and menu up

CH-

Programme/Channel down and menu down
