F

Connecting optional components

You can connect a wide range of optional components to your TV. Connecting
cables are not supplied.

Connecting to the TV (front)

• If you connect a VCR to

8

(antenna input), preset the signal output from the VCR to the

program number 0 on the TV (see

N

).

• When both

 (S video) and

 (video) for

t

2

are connected at the same time,

(S video) is automatically selected. To view

 (video), disconnect the S video cable.

• The component video terminals on your DVD player are sometimes labeled Y/C

B

/C

R

,

Y/P

B

/P

R

, Y/C

b

/C

r

 or Y/B-Y/R-Y.

• If you select “HD/DVD 1” or “HD/DVD 2” on your TV screen, the signal from the

T

(monitor output) terminals will not be output properly. This does not indicate a
malfunction.

• The TV accepts the following signal formats:

Total scanning line

1125i

750p

625p

625i

525p

525i

Effective scanning line

1080i

720p

576p

576i

480p

480i

fV (Hz)

50/60

50/60

50

50

60

60

Connecting to the TV (rear)

S Video cable

Audio/Video cable

Camcorder

Headphones

1

1

3

2

L

C

Y

R

P /

R

C

B

P /

B

R

(MONO)

L

R

Component

video cable

DVD Player

Digital TV receiver

Audio cable

Audio/Video cable

Audio/Video cable

Antenna cable

VCR

DVD Player

Audio System

VCR

L(MONO)

R
