Connection

4

Connection

Connection

Antenna input
•  Connect an external DVB-T antenna

(cable) connector to the antenna RF IN.

  The signal in the block cable antenna

can fail to contain DVB-T/T2 signal due to the
carrier frequency altered by the cable network
operator.

RF output
•  Connect the RF output jack to an antenna

cable to bypass the digital signal to other
devices.

HDMI-out
•  If your TV has an HDMI video output,

connect it to an HDMI output of this unit using
a special HDMI cable (not included).

Coaxial output
•  Connect the coaxial digital audio output to

the input of an amplifier to transmit the audio
signal to the amplifier using a special coaxial
cable (not included).

Stereo audio output
•  Connect the left (white) and right (red)

terminal of the stereo audio output to the
corresponding audio inputs on your TV using
the supplied RCA-type cable.

Composite vudeo (CVBS) output
•  Connect the yellow video output to the

composite video input on your TV using the
RCA cable  (included) for transmitting the
composite video signal.

Component video (YPbPr) output
•  Connect the component video output to

component video input on your TV using a
special cable (not supplied) to send component
video signal.

4
