English

7

Hilfe bei Störungen

Störungen haben oft einfache Ursachen, die Sie mit Hil-
fe der folgenden Übersicht selbst beheben können. Im
Zweifelsfall oder bei hier nicht genannten Störungen
wenden Sie sich bitte an den autorisierten Kunden-
dienst.

Nachlassende Saugleistung

Das Zubehör, der Saugschlauch oder die Saugrohre
sind verstopft.



Die Verstopfung mit einem geeigneten Hilfsmittel
entfernen.

Der Filterbeutel ist voll



Den Filterbeutel ersetzen.

Der Flachfaltenfilter ist verschmutzt.



Den Flachfaltenfilter reinigen (siehe Kapitel

Filterkassette / Flachfaltenfilter reinigen

).

Der Flachfaltenfilter ist beschädigt.



Den Flachfaltenfilter ersetzen.

Technische Daten

Hinweis

Die Technischen Daten befinden sich auf dem Typen-
schild.

General notes

Read these original operating instruc-
tions and the enclosed safety instruc-
tions before using the device for the first

time. Proceed accordingly.
Keep both books for future reference or for future own-
ers.

Intended use

Only use the device in private households.
In accordance with the descriptions and the safety infor-
mation in these operating instructions, the device is in-
tended for use as a wet and dry vacuum cleaner.
Cold ashes may only be vacuumed with suitable acces-
sories.
Protect the device from rain and do not store it outdoors.

Note

The manufacturer accepts no liability for possible dam-
age caused by improper use or incorrect operation.

Environmental protection

The packing materials can be recycled. Please
dispose of packaging in accordance with the en-
vironmental regulations.
Electrical and electronic appliances contain valu-
able, recyclable materials and often components
such as batteries, rechargeable batteries or oil,
which - if handled or disposed of incorrectly - can

pose a potential threat to human health and the environ-
ment. However, these components are required for the
correct operation of the appliance. Appliances marked
by this symbol are not allowed to be disposed of togeth-
er with the household rubbish.

Notes on the content materials (REACH)

Current information on content materials can be found
at:

www.kaercher.com/REACH

Accessories and spare parts

Only use original accessories and original spare parts.
They ensure that the appliance will run fault-free and
safely.
Information on accessories and spare parts can be
found at

www.kaercher.com

.

Scope of delivery

The scope of delivery for the appliance is shown on the
packaging. Check the contents for completeness when
unpacking. If any accessories are missing or in the
event of any shipping damage, please notify your deal-
er.

Warranty

The warranty conditions issued by our relevant sales
company apply in all countries. We shall remedy possi-
ble malfunctions on your appliance within the warranty
period free of cost, provided that a material or manufac-
turing defect is the cause. In a warranty case, please
contact your dealer (with the purchase receipt) or the
next authorised customer service site.
(See overleaf for the address)

Description of the device

Depending on the model selected, there are differences
in the equipment. The specific equipment is described
on the device packaging.
For the illustrations, refer to the graphics page.

Illustration A

1

Suction hose connection

2

Rotary switch

3

Carrying handle

4

Parking position handle / accessory holder

5

Filter box with unlocking button

6

Cable hook

7

Hose storage (both sides)

8

Storage area

9

Container closure

10

Rating plate with technical data (e.g. container size)

11

Mains connection with mains plug

12

Parking position for floor nozzle

13

Accessory storage

14

Steering roller

15

Filter bag

16

Flat pleated filter

17

Removable handle

18

Suction hose with connection piece

19

Suction tubes 2 x 0.5 m

20

Crevice nozzle

21

Floor nozzle

Installing the steering rollers

1. Before initial startup, remove the contents from the

container and mount the steering rollers.

Illustration B
Illustration C
Illustration D

Note

For versions with stainless steel tubes, remove the pro-
tective cover before initial startup.
