 English |

21

Bosch Power Tools

1 609 92A 0XF | (30.9.14)

Noise Information

Sound emission values determined according to
EN 60335-2-69.

Typically the A-weighted sound pressure level of the vacuum
cleaner is lower than 70 dB(A). Uncertainty K = 3 dB.
The noise level when working can exceed 80 dB(A).

Wear hearing protection!

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, 2014/30/EU,
2006/42/EC including their amendments and complies with
the following standards: EN 60335-1, EN 60335-2-69.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 30.09.2014

Assembly



Before any work on the vacuum cleaner itself, pull the
mains plug.

Mounting the Vacuum-hose Holder (see figure A)

– Slide the vacuum-hose holders

4

 firmly from above into the

retainers

36

 intended for this purpose, until they engage.

Mounting the Vacuum Hose (see figure B)

– Mount  the  vacuum  hose

27

 onto the hose connection

piece

3

 and turn it in clockwise direction to the stop.

Note:

While vacuuming, an electrostatic charge develops in

the vacuum hose and accessories caused by the friction of the
dust, which the operator could experience in the form of stat-
ic discharging (dependent on environmental influences and
physical perception).
As a general rule, Bosch recommends using an anti-static vac-
uum hose (accessory) when vacuuming fine dusts and dry
materials.

Mounting VAC Accessories (see figure C)

The vacuum hose

27

 is equipped with a clip system, with

which the VAC accessories (tool sleeve

25

, elbow

28

) can be

connected.

Mounting the Tool Sleeve

– Mount the tool sleeve

25

 onto the vacuum hose

27

 until

both snap-fasteners

37

 of the vacuum hose can be heard

to engage.

– To disassemble, press both snap-fasteners

37

 inward and

pull the components apart.

Mounting Nozzles and Tubes

– Mount  the  elbow

28

 onto the vacuum hose

27

 until both

snap-fasteners

37

 of the vacuum hose can be heard to en-

gage.

– Afterwards, mount the desired VAC accessory (floor noz-

zle, crevice nozzle, vacuum tube, etc.) firmly onto the el-
bow

28

.

– To disassemble, press both snap-fasteners

37

 inward and

pull the components apart.

Inserting/Removing a Disposal Bag or Dust
Bag (Dry Vacuuming) (see figure D)

For dry vacuuming of materials according to dust category M,
a disposal bag

29

 or a dust bag

must

 be inserted.

When vacuuming materials with or without an exposition limit
value ≥ 1 mg/m

3

 (according to dust category L), it is possible

to vacuum directly into the container.

Note:

When using a paper filter bag, the automatic filter

cleaning (AFC) (see “Deactivating the AFC”, page 23)

must

,

and when using a fleece filter bag,

should

 be shut off.

Do not fill the disposal bag

29

 with more than

25 kg (max.)

.

The vacuum cleaner contains materials
that are hazardous to one’s health.

Have the emptying and maintenance, incl. the disposal of
dust-collection containers, carried out only by specialists.
Appropriate protective equipment is required. Do not op-
erate the vacuum cleaner without the complete filter sys-
tem.

Otherwise there is danger to your own health.

Inserting a Disposal Bag

– Unlock the latches

15

 and remove the vacuum lid

13

.

– Insert the disposal bag

29

 into the container

1

 with the fill-

ing opening toward the front.

– Pull the filling opening over the connection flange into the

recess of the connection flange.

– Make sure that the disposal bag

29

 faces completely

against the interior sides of the container

1

.

– Fold the rest of the disposal bag

29

 over the edge of the

container

1

.

– Reattach the vacuum lid

13

 again and lock the latches

15

.

Removing and Closing the Disposal Bag

– Unlock the latches

15

 and remove the vacuum lid

13

.

– Pull the full disposal bag

29

 toward the rear off of the con-

nection flange.

– Carefully remove the disposal bag

29

 out of the vacuum

cleaner without damaging it.
When doing this, pay attention that the disposal bag does
not get caught or ripped open against the connection
flange or other sharp objects.

– Pull the cover off of the adhesive strip, close the disposal

bag and tape it shut.
Afterwards, tie off the disposal bag

29

 below the filling

opening with the pulled off cover of the adhesive strip.

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9

WARNING
