– Pull the full dust bag backwards out of the connection

flange. Close the opening in the dust bag by turning down
the top. Take the closed dust bag out of the container

(1)

.

– Place the new dust bag over the vacuum cleaner's con-

nection flange. Make sure that the entire length of the
dust bag touches the inside wall of the container

(1)

.

– Put the top part of the vacuum cleaner

(10)

 on and close

the catches

(11)

.

Fitting the rubber lip (wet vacuuming) (see
figure E)

Note:

 The requirements for the degree of penetration (dust

class L) have only been verified for dry vacuuming.
– Use a suitable tool to lift the brush inserts

(27)

 out of the

floor nozzle

(28)

.

– Place the rubber lips

(26)

 in the floor nozzle

(28)

.

Note:

 The textured side of the rubber lips must be facing

outwards.

Attaching the L-Boxx (see figure F)

You can attach an L-Boxx to the top part of the dust extractor
for transporting the extractor and to provide space-saving
storage for extractor accessories and/or the power tool.
– Click the L-Boxx onto the adapters

(9)

.

u

Do not use the dust extractor with an L-Boxx attached.

This will raise the dust extractor's centre of gravity. The
extractor may tip over. There is a risk of injury and dam-
age if you do this.

u

Do not carry the dust extractor by the carrying handle
of the attached L-Boxx.

 The dust extractor is too heavy

for the carrying handle of the L-Boxx. There is a risk of in-
jury and damage if you do this.

Operation

u

Pull the plug out of the socket before cleaning or per-
forming maintenance on the vacuum cleaner, making
tool adjustments, changing accessories or putting
away the vacuum cleaner.

 This safety measure prevents

the vacuum cleaner from being started accidentally.

Start-up

u

Pay attention to the mains voltage.

 The voltage of the

power source must correspond with the information on
the type plate of the dust extractor. Chargers labelled as
230 V can also be operated with 220 V.

u

Pay attention to the mains voltage.

 The voltage of the

power source must correspond with the data on the type
plate of the vacuum cleaner.

u

Make sure you inform yourself about the applicable
regulations/laws on how to handle harmful types of
dust in your country.

The dust extractor may be used for vacuuming and extract-
ing the following materials:
– Dusts with an exposure limit of > 1 mg/m

3

u

Products that are only sold in AUS and NZ:

 Use a resid-

ual current device (RCD) with a nominal residual current
of 30 mA or less.

The dust extractor must categorically not be used in poten-
tially explosive areas.
To ensure optimum suction power, you must always fully un-
wind the vacuum hose

(21)

 from the top part of the dust ex-

tractor

(10)

.

Dry vacuuming

Vacuuming up dust deposits

– To

switch on

 the dust extractor, set the

mode selector switch

(6)

 to the "extraction"

symbol.

– To

switch off

 the dust extractor, set the

mode selector switch

(6)

 to the "switch off"

symbol.

Extracting dust that accumulates from working power
tools (see figure G)

u

There must be a sufficient air exchange rate (L) in the
room when the exhaust air comes back into the room.
Be aware of the corresponding national regulations.

The dust extractor has an electric socket with a protective
earth contact

(4)

, which can be used to connect an external

power tool. Observe the maximum permitted load of the
connected power tool.
– Fit the dust extraction adapter

(20)

 (see "Fitting the dust

extraction adapter", page 20).

– Insert the dust extraction adapter

(20)

 into the dust ex-

traction outlet of the power tool.

Note:

 When working with power tools that have a low air

feed into the vacuum hose (e.g. jigsaws, sanders, etc.), the
false air intake

(32)

 of the dust extraction adapter

(20)

 must

be opened. This will ensure that the automatic filter cleaning
function works correctly.
To do this, turn the ring above the false air intake

(32)

 until

the opening is at its maximum size.

– To

activate the automatic start/stop

function of the dust extractor, set the
mode selector switch

(6)

 to the "auto-

matic start/stop" symbol.

– To

activate

 the dust extractor, switch on the power tool

that is plugged into the electric socket

(4)

. The dust ex-

tractor will start automatically.

– To

stop

dust extraction

, switch the power tool off.

The automatic start/stop run-on function will run for up
to 15 seconds longer in order to extract the remaining
dust from the vacuum hose.

– To

switch off

 the dust extractor, set the

mode selector switch

(6)

 to the "switch

off" symbol.
