20

 | English

1 609 92A 4M0 | (16.11.2018)

Bosch Power Tools

Automatic start/stop

Rated voltage

Maximum power

Minimum power

230 V

2200 W

100 W

Permitted connected load of the connected power tool.
These values can differ for other country-specific models. Please take note of the information on the socket of the dust extractor.

Noise/vibration information

Noise emission values determined according to

EN

60335-2-69

.

Typically the A-weighted sound pressure level of the dust ex-
tractor is

70

 dB(A). Uncertainty K =

3

 dB. The noise level

when working can exceed

80

 dB(A).

Wear hearing protection

Total vibration values a

h

 (triax vector sum) and uncertainty K

determined according to

EN 60335-2-69

: a

h

<

2.5

 m/s

2

,

K =

1.5

 m/s

2

.

Assembly

u

Pull the plug out of the socket before carrying out any
work on the dust extractor.

Fitting the holder for the vacuum hose (see
figure A)

– Slide the holder

(5)

 for the vacuum hose firmly into the

corresponding adapters

(30)

 from above until they click

into place.

Fitting the vacuum hose (see figure B)

– Attach the vacuum hose

(21)

 to the hose adapter

(2)

 and

turn it clockwise as far as possible.

Note:

 The friction generated by the dust in the vacuum hose

and accessory during extraction causes an electrostatic
charge that the user may experience as static discharge (de-
pending on environmental factors and their physiological
state).
Bosch generally recommends using an anti-static vacuum
hose (accessory) to vacuum up fine dust and dry materials.

Fitting the vacuuming accessories (see figure C)

The vacuum hose

(21)

 is equipped with a clip system which

can be used to connect vacuuming accessories (dust extrac-
tion adapter

(20)

, curved nozzle

(22)

).

Fitting the nozzles and tubes

– Push the curved nozzle

(22)

 onto the vacuum hose

(21)

until you hear both snap fasteners

(31)

 on the vacuum

hose engage.

– Then attach the required extraction accessory (floor

nozzle, crevice nozzle, suction tube, etc.) firmly to the
curved nozzle

(22)

.

– To remove the accessory, press the snap fasteners

(31)

inwards and pull apart the components.

Fitting the dust extraction adapter

– Push the dust extraction adapter

(20)

 onto the vacuum

hose

(21)

 until you hear both snap fasteners

(31)

 on the

vacuum hose engage.

– To remove the adapter, press the snap fasteners

(31)

 in-

wards and pull apart the components.

Inserting/removing the disposal bag or dust bag
(dry vacuuming) (see figures D1–D2)

For dry vacuuming, you can insert a disposal bag

(23)

 or a

dust bag (accessory) into the container

(1)

. This makes the

dust easier to dispose of.

Note:

 If using a paper filter bag, you

must

 make sure that the

automatic filter cleaning is switched off; you

should

 also do

the same if using a fleece filter bag (see "Automatic filter
cleaning (see figure

H

)", page 22).

Inserting the disposal bag

– Open the catches

(11)

 and remove the top part of the va-

cuum cleaner

(10)

.

– Insert the disposal bag

(23)

 into the container

(1)

 with

the inlet facing forwards.

– Pull the inlet over the connection flange and all the way

into the recess of the connection flange.

– Make sure that the disposal bag

(23)

 touches all the in-

side walls of the container

(1)

.

– Fold the rest of the disposal bag

(23)

 over the edge of the

container

(1)

.

– Put the top part of the vacuum cleaner

(10)

 on and close

the catches

(11)

.

Removing and sealing the disposal bag

– Open the catches

(11)

 and remove the top part of the va-

cuum cleaner

(10)

.

– Pull the full disposal bag

(23)

 backwards out of the con-

nection flange.

– Carefully take the disposal bag

(23)

 out of the container

(1)

 without damaging it.

When doing so, make sure that the disposal bag does not
scrape against the connection flange or other sharp ob-
jects.

– Remove the adhesive strip cover and tape up the disposal

bag.
Then tie up the disposal bag

(23)

 below the inlet using

the adhesive strip cover that has been removed.

Changing/inserting the dust bag (accessory)

– Open the catches

(11)

 and remove the top part of the va-

cuum cleaner

(10)

.
