15

СТАРТ/ПАУЗА

Нажмите  кнопку

H

  после  установки  всех  выбранных  настроек,  цикл  стирки  будет  запущен.  На

дисплее загорится соответствующий LED-индикатор. Во время цикла стирки прибор можно ставить

на паузу, удерживая в течение нескольких секунд кнопку

H

. Во время стирки Вы можете поставить

стиральную  машину  на  паузу,  для  этого  нажмите  кнопку  СТАРТ/ПАУЗА  и  удерживайте  в  течении

нескольких  секунд.  После  этого  ранее  выбранные  настройки  могут  быть  изменены  (возможность

изменения настроек зависит от выбранной программы и фазы стирки). Также по истечении 2 минут

(если температура воды ниже 50°C) после активации паузы, можно открыть люк для дополнительной

загрузки/извлечения белья. Чтобы возобновить цикл стирки нажмите на

H

еще раз.

В Н И М А Н И Е! Е С Л И В Р Е Ж И М Е П АУ З Ы Н Е П Р О И З В ОД И Т Ь Н И К А К И Х Д Е Й СТ В И Й,

ТО П Р О Ц Е СС СТ И Р К И Б УД Е Т В О З О Б Н О В Л Ё Н А ВТО М АТ И Ч Е С К И В Т Е Ч Е Н И Е 5

М И Н У Т.

БЛОКИРОВКА УПАВЛЕНИЯ (ЗАЩИТА ОТ ДЕТЕЙ)

Для  блокировки  панели  управления  и  предотвращения  непреднамеренного  нажатия,  нажмите

одновременно кнопки

B

 и

E

. На дисплее высветятся три горизонтальные линии.

Для снятия блокировки нажмите повторно

B

 и

E

.

ДЕЗИНФЕКЦИЯ БАКА

Данная  модель  снабжена  функцией  автоочистки  бака  стиральной  машины,  что  предотвращает

образование  плесени  и  неприятных  запахов  после  длительного  периода  эксплуатации  прибора.

Функция предполагает очистку бака с помощью специального цикла при температуре 90°C.

В случае, если Ваша стиральная машина долгое время работала при низкой температуре на дисплее

появится напоминание о необходимости активации функции Дезинфекции: высветится символ CLn.

Извлеките всё бельё из машины, установите регулятор

I

в положение Дезинфекция бака, нажмите

кнопку

H

 для активации программы.

Автоочистка может запускаться при необходимости так часто, как это требуется:

извлеките всё бельё

из машины, установите регулятор

I

в положение Дезинфекция бака, нажмите и удерживайте кнопку

предварительной стирки до появления на дисплее символа CLn, нажмите кнопку

H

 для активации.

4

CONTROL PANEL

EN

RINSE:

 Press the

F

 button to activate the extra rinse function. This option is recom-

mended if your skin is particularly sensitive to enzymes in detergents.

DELAYED START:

 This feature allows you to delay the start of the wash cycle up to

a maximum of 19 hours. Press the

B

  button repeatedly until the display shows the

desired start delay. The icon

:

flashes on the display until the start of the wash cycle.

When the function is activated, the display will turn off the backlight after a few sec-
onds to save energy. To reactivate, press any button on the display.

PREWASH:

 To perform a prewash, press the

D

 button and put the detergent in the

drawer

1

. The washing machine performs a prewash cycle at 40°C, max. Prewash

is recommended for garments soiled with dust, dirt and sand or with particularly
stubborn stains. See the program table for further information.

LCD DISPLAY:

The large LCD display ensures quick and intuitive use of the washing

machine. The display shows the wash options enabled, any delayed start, spin speed

selected and the time remaining until the end of the cycle. The word End means that

the door has been released.
After a few seconds, from the end of the wash

cycle, the display switches off with the word

End.  To reactivate the display, press any button

on the display.

TURBO:

 Press the

E

 turbo button to reduce the wash time. The operating parameters

are automatically adjusted to ensure washing effectiveness and to allow time to be
saved. See the program table for further information.

ADJUSTABLE SPIN

 Pressing the

C

 button, the spin speed can be adjusted depend-

ing on the wash program selected and the type of fabric. The LCD display will show
the speed selected. The “

00

” value will exclude the spin cycle at the end of the cycle.

N.B.:

 The maximum spin speed varies depending on the model. The speed matched

to each program is the one recommended.

Unbalanced load control during spin cycle:

This washing machine is equipped with a special electronic control system for proper load balanc-
ing. Prior to every spin, the system makes sure that the cloths are spread as evenly as possible in
the drum.   In the case of uneven laundry distribution, for safety reasons, the final spin speed will be
reduced and in cases of high load imbalance, will not be performed.
