9

When switching between the «On» and
«Reverse» positions, be sure to move the
button to the «Stop» position for 5 seconds to
stop the auger.

To avoid overheating of the motor, do not use
this device for more than 10 minutes without
a pause. The break between cycles should
be 5 minutes.

Do not place ingredients that are hotter than
80°C into the feeding bowl. Let them cool
down.

Do not use a spoon or other foreign objects
in order to remove the pulp from the pulp
spout as it may damage the device.

To push the ingredients into the feeding chu-
te, use only the pusher, which is included
with the device. It is strictly forbidden to push
ingredients with hands, as this could cause
injury.

ORDER OF OpERATION,

Pic.E

1.  Assemble the device, Pic. D. Plug in the device.
2.  Press the power button, Pic. C-2.
3.  Using the pusher, place the prepared ingredients into

the filling hole, Pic. E. The products should be cut

into pieces for the JM4600 model. For the JM4700,
you can use whole or cut ingredients. To place whole
ingredients, remove the lid from the feeding bowl, Pic.
B- 11.

Note:

•

Follow the cooking guidelines to prepare the ingre-
dients.

•  Do not overfill the feeding bowl.

UTILIZATION,

Pic. D

Before first use,

wipe the device with a soft, dry cloth.

The rest of the parts wash with warm water and deter-
gent.

Before assembling or disassembling the device

and / or removing attachments, make sure that the

device is unplugged.
Step 1,

 Pic. D-1

Take the filter and place the silicone ring on it, aligning

the tab on the ring with the slot in the filter. Press lightly

on the silicone ring. Make sure the silicone ring is firmly

seated on the filter.

Step 2,

 Pic. C-3

Place the bowl with spouts on the motor unit. For model
JM4600, align the two marks as shown in the illustration.
For model JM4700, align the juice and pulp spouts with
the grooves on the motor block.

Step 3,

Pic. C-4

Insert the auger/pressure screw into the center of the
spout bowl by gently pushing and turning until it snaps
into place.

Step 4,

 Pic. C-5

Insert the filter into the bowl with the spouts, with the

silicone ring facing down. Note the position of the largest

ridge on the filter. Make sure the dots on the filter and

bowl are aligned as shown in the illustration.

Step 5,

Pic. C-6

Place the feeding bowl on the bowl with spouts and turn
it clockwise as shown in the fpicture. Place the lid on the
feeding bowl (for model JM4700).

Note: Always leave the spout lid open when juicing
ingredients that produce a lot of foam, Pic. C-1.

The power button is located on the handle of the device.

The key has three positions (Pic. C-2):

ON (



) – turn on;

0

 – Pause /stop motor;

REV (



) – Reverse.

Place the pulp container and juice container under
the respective spouts. After completing the assembly,
plug in the device.

4.  If a dense mass of ingredients gets stuck in the juicer

mechanism and impedes the movement of the juice,
move the button to the “Stop” position until the engine
comes to a complete stop, then move the button to
the “Reverse” position. The auger will start to rotate
in the opposite direction.After a few seconds, again
move the button to the “Stop” position and after stop-
ping the engine, press “ON”. Repeat this operation if
necessary.

5.  At the end of juicing, close the lid at the spout so

that the remaining juice does not drip onto the table.

Switch off the device and unplug it.

Note: Freshly squeezed juices are recommended to
be consumed immediately after preparation, as after

a while they begin to exfoliate and lose their beneficial

properties.

pREpARATION REcOMMENDATIONs

1.  Do not place into the device dried or hard ingredients,

such as whole grains, fruits with hard seeds, thick-
skinned or ice. This can damage juice maker’s parts.

2.  Beans or grain can be used if they were presoaked

overnight and boiled.

3.  Do not press the products without juice content (coco-

nut, sugar cane, whole grains, etc.).

4.  Do not use ingredients that contain an excessive

amount of vegetable oil or animal fat. Do not use the
juice maker for squeezing oil from the ingredients.
If the plant oil or animal fat falls onto the pressure
screw, it can reduce performance and damage juice
maker’s parts.

5.  Do not load pulp into the juice maker. This can lead to

a shutdown or lock the juice cup’s lid.

6.  After juicing the ingredients with small seeds, you

must clean all parts of the device from the seeds.

7.  The amount of juice depends on the freshness and

juiciness of the products. The fresher the vegetables
or fruit, the more juice you can make.
